Kymco
Workshop-manual
kxr 50 90 Workshop-manual
Page 27
kxr 50 90 Workshop-manual : Page 27
Page 25
Page 26
Page 28
Page 29
1
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
185
190
195
200
205
210
215
220
225
230
235
240
245
246
1. GENERAL INFORMATION Mongoose/KXR 90/50 WIRING DIAGRAM (KXR 50 ON ROAD) 1-24
