          2. GENERAL INFORMATION                                               STRYKER 125/150


             Tool Name             Tool No.                    Remarks
 Pilot                                        Final shaft bearing installation
 Bearing outer driver, 37x40mm                Drive shaft bearing installation
                                              Final shaft bearing installation
 Outer driver, 24x26mm                        Drive shaft bearing installation
 Pilot, 10mm                                  Front wheel bearing installation
 Bearing driver pilot, 17mm                   Drive shaft bearing installation
                                              Drive shaft bearing installation
                                              Final shaft bearing installation
 Bearing outer driver handle (A)              Bearing installation


 Bearing puller head, 10mm                    Front wheel bearing removal
                                              Front/rear shock absorber disassembly/
 Shock absorber compressor                    assembly
 Bearing puller                               Front wheel bearing removal
 Pressure tester set                          Cylinder compression gauge
