9. DRIVE AND DRIVEN PULLEYS/
KICK STARTER AGILITY CITY 125
Clutch Outer
Install the clutch outer.
Hold the clutch outer with the universal
holder.
Install and tighten the clutch outer nut.
Torque: 5.5kg-m
Special
Flywheel Holder
Install the drive belt.
Install the left crankcase cover.
Flywheel Holder
KICK STARTER
REMOVAL
Remove the left crankcase cover.
Remove the seal rubber and dowel pins.
Left Crankcase Cover
Kick Starter Spindle
Remove the kick lever.
Remove the circlip and washer from the kick
starter spindle.
Circlip
Gently turn the kick starter spindle to remove
the starter driven gear together with the
friction spring.
Friction Spring Starter Driven Gear
9-13
