12. FRONT WHEEL/FRONT BRAKE/
FRONT SUSPENSION AGILITY CITY 50
BRAKE MASTER CYLINDER Brake Master Cylinder Bolts
Removal
First drain the brake fluid from the hydraulic
brake system.
· When servicing the brake system, use
shop towels to cover rubber and
plastic parts and coated surfaces to
avoid being contaminated by brake
fluid.
· When removing the brake fluid pipe
bolt, be sure to plug the pipe to avoid
b k fl id l k
Disassembly Snap Ring
Remove the piston rubber cover and snap
ring from the brake master cylinder.
Remove the washer, main piston and spring Main Piston Spring Master Cylinder
from the brake master cylinder.
Clean the inside of the master cylinder and
brake reservoir with brake fluid.
Snap Ring
12-10
