10. A.C. GENERATOR/STARTER CLUTCH DINK 50/125
Bolts
Install the A.C. generator stator and pulser
coil onto the right crankcase.
Tighten the stator and pulser coil bolts.
Torques: Pulser Coil : 0.45~0.6kgf-m
Stator : 0.8~1.2kgf-m
Install the A.C. generator wire rubber sleeve
and A.C. generator wire set plate.
Bolts
Connect the A.C. generator wire connector.
Connectors
Woodruff Key
Clean the taper hole in the flywheel off any
burrs and dirt.
Install the woodruff key in the crankshaft
keyway.
10-14
