13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK DINK 50/125
Float Float Pin
Remove float pin, float and float valve.
(You will use hammer Remove the float pin)
Float Valve Hammer
Float Valve
FLOAT VALVE INSPECTION
Inspect the float valve seat contact area for
wear.
Float Valve Seat
JETS/SCREWS REMOVAL
· Before removing the pilot screw, turn
the pilot screw clockwise until it seats
lightly and record the rotating turns.
Do not force the pilot screw against its
seat to avoid seat damage.
Pilot Screw
13-32
