8. DRIVE AND DRIVEN PULLEYS
K-XCT 125i
DRIVE PULLEY INSPECTION
Weight rollers
Check each roller for wear or damage.
Measure outside diameter.
Service limit: 19.8 mm (0.792 in)
Movable drive face/Slide pieces/Drive
pulley face
Ramp Plate
Check the movable drive face splines for
wear, cracks or damage.
Check the ramp plate for cracks or damage.
Check the movable drive face and drive
pulley face cracks or damage.
8-10
