16. STARTING SYSTEM Mongoose/KXR 90/50
Reduction Gear Case
STARTER PINION
(Mongoose/KXR 90)
REMOVAL
Remove the left crankcase cover and drive
pulley face. (Refer to chapter 9)
Remove starter one-way clutch drive.
Special
Start clutch puller E006 Starter One-way Clutch Drive Nut
Remove the reduction gear case.
Remove the reduction gear.
INSTALLATION Starter Gear Shaft Reduction Gear
Install each washer to the top and bottom of
the reduction gear.
Apply grease to the reduction gear shaft
forcing part.
Then, install in the reverse order of
removal.
Washers Reduction Gear Case
Starter Oneway Clutch Drive Gear
STARTER ONE-WAY CLUTCH
DISASSEMBLY
Remove the 32mm lock nut with special
tool.
Take the starter one-way clutch drive gear
off.
Special
Lock nut socket wrench E015
Universal holder E017
32mm Lock Nut
16-7
