10.FINAL REDUCTION/
TRANSMISSION SYSTEM MXU 300/250
Splines
INSPECTION
Inspect the secondary driven bevel gear shaft
splines for wear or damage.
Inspect the secondary driven bevel gear shaft
for blue discoloration, pitting or wear.
Inspect the bevel gears and speedometer gear Bevel Gear Bevel Gear
for blue discoloration, pitting or wear.
Speedometer Gear
Secondary Driven Bevel Gear Shaft
SECONDARY DRIVEN BEVEL GEAR
ASSEMBLY
Apply engine oil to the secondary driven
bevel gear shaft.
Install the secondary driven bevel gear shaft
into the case.
10-25
