6. ENGINE REMOVAL/INSTALLATION MXU 250R/300R
ENGINE INSTALLATION (MXU
250R)
Installation is in the reverse order of
removal.
The rear upper and lower engine mounting
bolts and nuts loosely install, then tighten
the engine mounting nuts to the specified
torque.
Torque: 40 N-m (4 kgf-m, 29 lbf-ft)
The brackets, bolts, front engine mounting
bolt and loosely install, then tighten the
bolts on the brackets to the specified torque.
Torque: 22 N-m (2.2 kgf-m, 16 lbf-ft)
Tighten the front engine mounting bolt and
nut to the specified torque.
Torque: 40 N-m (4 kgf-m, 29 lbf-ft)
6-7
