15. REAR WHEEL/AXLE/SUSPENSION
DRIVING MECHANISM MXU 250R/300R
Remove the rear brake disk.
Rear Brake Disk
Inspect the brake disk
Cracks/damage Replace.
Inspect the brake disk splines.
Wear/damage Replace.
Splines
Drive Sprocket Cover Bolts
Loosen the driven chain (refer to the
"DRIVE CHAIN SLACK ADJUSTMENT"
section in the chapter 3) and remove the two
bolts at the drive sprocket (refer to the
chapter 6), then disconnect the drive chain
from the driven sprocket.
Bolts Drive Sprocket
15-7
