15. REAR WHEEL/AXLE/SHOCK
ABSORBER/SWING ARM MXU550EXi/MXU500i
REAR WHEEL HUB Nut/Washer
REMOVAL/INSPECTION/
INSTALLATION
REMOVAL
Place the machine on a level place.
Remove the rear wheel (refer to the "REAR
WHEEL REMOVAL/INSPECTION/
INSTALLATION" section in this chapter)
Elevate the rear wheels by placing a suitable
stand under the frame.
Support the machine securely so there is Cotter Pin
no danger of it falling over.
Remove the cotter pin.
Apply the rear brake and then remove nut
and rear wheel hub.
INSPECTION
Apply grease
Check the wheel hub for cracks or damage.
Check the wheel hub splines for wear or
damage.
15-4
