6. CYLINDER HEAD/VALVES People GT 125i
CAMSHAFT HOLDER
REMOVAL
Turn the A.C. Generator Flywheel so that the
T mark on the flywheel aligns with the index
mark on the crankcase.
Hold the round hole on the camshaft gear
facing up and location is the top dead center
on the compression stroke.
Remove the two bolts attaching the tensioner
Remove the four cap nuts and cylinder two
bolts washers from camshaft holder and
cylinder two bolts then remove the cam shaft
Bolt.
Remove the camshaft gear and holder
Bolt.
INSTALLATION
Install the camshaft gear, Holder bolt and
holder washers and nuts.
Tighten the four cylinder head nuts to the
specified torque.
Torque:
0.7~1.1 kgf-m (Holder nuts)
1.0~1.4 kgf-m (Cam shaft set plate)
1.8~2.2 kgf-m (Cylinder head M8 *1.25)
· Install the camshaft holder with the
"EX" mark face exhaust valve side.
· Apply engine oil to the threads of the
cylinder head cap nuts.
· Diagonally tighten the cylinder head
cap nuts in 23 times.
6-5
