12. CARBURETOR SUPER 9 50
Connect the auto bystarter yellow wire to
the battery positive (+) terminal and green/
black wire to the battery negative (-)
terminal and wait 5 minutes.
Connect a hose to the fuel enriching circuit
and blow the hose with mouth.
If air can be blown into the hose, the auto
bystarter is faulty and replace it with a new
one.
AUTO BYSTARTER REMOVAL Auto Bystarter
Remove the auto bystarter cover.
Remove the two auto bystarter set plate
screws to remove the auto bystarter.
Set Plate Screws
Check the auto bystarter valve and needle
O-ring
for wear or damage.
Check the O-ring for wear or damage.
Bystarter Needle Bystarter Valve
12-6
