12. CARBURETOR SUPER 9 50
FLOAT/FLOAT VALVE INSPECTION Float Valve
Inspect the float for damage or fuel inside
the float.
Check the float valve seat for wear or
damage.
Float Seat
JETS/SCREWS REMOVAL Main Jet
Before removing the throttle stop screw or
air screw, record the number of rotations
until it seats lightly. Then, remove them.
Do not force the air screw against its
seat to prevent damage.
Remove the main jet and needle jet holder.
Throttle Stop Screw Air Screw
CARBURETOR PASSAGES CLEANING
Blow compressed air through all passages
of the carburetor body with an air gun.
12-8
