3. INSPECTION/ADJUSTMENT UXV 500
3. Loosen the lock nut and adjuster on the
cable.
4. Turn the adjuster until the caliper lever is
about to rotate then Tighten the lock nut.
Adjuster
Parking brake cable end length:
L: 53 2 mm (2.12 0.08 in)
5. Slowly turn the adjusting bolt on the
caliper clockwise until resistance is felt,
then turn adjusting bolt 1/8
counterclockwise.
6. Tighten the lock nut to the specified
torque while hold the adjusting bolt.
Torque:
1.6 kgf-m (16 N-m, 11.52 lbf-ft)
3-30
