3. LUBRICATION SYSTEM VITALITY 50
DAMPING DEVICE
SHOCK ABSORBERS
Oil Leak/Damage
Fully apply the front brake and check the
action of the front shock absorber by
compressing it several times.
Check the entire shock absorber assembly
for looseness or damage.
Check the action of the rear shock absorber
by compressing it several times.
Check the entire shock absorber assembly
for looseness or damage.
TRANSMISSION GEAR OIL 2-Stroke
TRANSMISSION OIL
MRASUREMENT
1. Place the scooter on its main
stand on level ground. After the engine
stops for 2~3 minutes.
2. Remove the oil filler bolt (1)
and check the oil level (2). It should be up
to the brim of the hole. If the level is low,
add oil to raise it to the proper level.
3. After refilling, securely tighten
the bolt (1).
Torque: 1.01.5kgf-m
Specified Gear Oil: SAE10W90#
TRANSMISSION OIL
REPLACEMENT
1. Place the scooter on a level place.
2. Place a container under the engine.
3-5
