5. FUEL SYSTEM AGILITY 125
Air Cleaner Connecting Vacuum Tube Intake Manifold
Tube Band Band
CARBURETOR INSTALLATION
Tighten the drain screw.
Install the carburetor onto the intake
manifold, aligning the tab on the carburetor
with the cutout in the intake manifold.
Tighten the intake manifold band screw.
Install the air cleaner connecting tube and
tighten the band screw.
Connect the throttle cable to the throttle
wheel on the carburetor.
Tighten the lock nut.
Throttle Cable Adjusting Nut Lock Nut
Connect the fuel tube and vacuum tube to
the carburetor.
Fuel Tube
Connect the auto bystarter wire connector.
Perform the following inspections and
adjustments:
-Throttle grip free play ( 3-3)
-Carburetor idle speed ( 3-5)
Auto Bystarter Wire Connector
5-10
