2. FRAME COVERS/EXHAUST MUFFLER Mongoose/KXR 90/50
Bolts
FOOT BOARD REMOVAL
Remove front fender. (See page 2-5)
Remover rear fender. (See page 2-6)
Remove the four bolts attaching the
right/left foot board.
FRONT CARRIER REMOVAL
Remove the four bolts attaching front
carrier at the right/left side.
Bolts
EXHAUST MUFFLER
REMOVAL
Remove the two nuts attaching the exhaust
pipe and cylinder head.
Nuts
Remove the three bolts attaching the
exhaust muffler, then remove the exhaust
muffler.
Bolts
2-7
