TRANSMISSION

VARIATOR / CLUTCH FOR KYMCO SENTO 100 4T EURO III

(1) 22100-KNBN-902

CLUTCH OUTER

(2) 22102-KHC4-900

FACE COMP DRIVE

(3) 22105-KHC4-900

BOSS DRIVE FACE

(4) 22110-KHC4-900

FACE COMP MOVABLE DRIVE

(5) 22121-GHT8-305

ROLLER SET WEIGHT 16X13 7,50 GR

(6) 22131-GCW3-901

PLATE RAMP

(7) 22132-LAB4-305

PIECE SLIDE SET

(8) 22300-LBC6-900

PLATE ASSY DRIVE

(9) 22350-KHC4-900

PLATE COMP DRIVEN

(10) 22401-LAB4-900

SPRING CLUTCH SHOES

(11) 22530-LBC6-900

MASSELOTTE D'EMBRAYAGE UNITE 169 GR

(12) 22804-1H48-C00

RUBBER CLUTCH DUMPER

(13) 2301A-LBC6-900

CORRECTEUR DE COUPLE

(14) 23100-KHC4-900

BELT DRIVE

(15) 23200-GCW3-001

FACE ASSY DRIVEN

(16) 23220-KHC4-900

FACE COMP MOVABLE DRIVEN

(17) 23225-GCW3-001

PIN ROLLER GUIDE

(18) 23226-GCW3-001

ROLLER GUIDE

(19) 23233-LAB4-900

SPRING DRIVEN FACE

(20) 23237-GCW3-001

COLLAR SPRING

(21) 23239-GCW3-851

COLLAR SPRING

(22) 28211-KNBN-901

RATCHET KICK STARTER

(23) 90202-1G87-C00

NUT SPECIAL (M28)

(24) 90442-0D44-001

WASHER THRUST (6MM)

(25) 90454-GBB2-C00

CIRCLIP (6MM)

(26) 91001-GGA7-C00

BEARING BALL (6901 U)(12X24X6)

(27) 91103-GAR1-00A

BEARING NEEDLE (17X25X18 WS)

(28) 91211-GHK8-014

OIL SEAL (34X39X3) - A

(29) 91351-6B42-000

O-RING (42X40X1,8)

(30) 91351-GAR1-001

O-RING (42X38,5X2)

(31) 94050-10080

NUT FLANGE (M10X10)

(32) 94050-12080

NUT FLANGE (M12X11)

(33) 94520-24000

CIRCLIP IN (24MM)

	Part number	Description	Qty
# 1	22100-KNBN-902	CLUTCH OUTER	28,25 €(24,31 £)
# 2	22102-KHC4-900	FACE COMP DRIVE	11,25 €(9,68 £)
# 3	22105-KHC4-900	BOSS DRIVE FACE	9,58 €(8,24 £)
# 4	22110-KHC4-900	FACE COMP MOVABLE DRIVE	12,42 €(10,69 £)
# 5	22121-GHT8-305	ROLLER SET WEIGHT 16X13 7, 50 GR	11,58 €(9,96 £)
# 6	22131-GCW3-901	PLATE RAMP	8,75 €(7,53 £)
# 7	22132-LAB4-305	PIECE SLIDE SET	3,33 €(2,87 £)
# 8	22300-LBC6-900	PLATE ASSY DRIVE	52,42 €(45,11 £)
# 9	22350-KHC4-900	PLATE COMP DRIVEN	9,58 €(8,24 £)
# 10	22401-LAB4-900	SPRING CLUTCH SHOES	1,25 €(1,08 £)
# 11	22530-LBC6-900	MASSELOTTE D'EMBRAYAGE UNITE 169 GR	Not available	0,00 €(0,00 £)
# 12	22804-1H48-C00	RUBBER CLUTCH DUMPER	2,50 €(2,15 £)
# 13	2301A-LBC6-900	CORRECTEUR DE COUPLE	Not available	0,00 €(0,00 £)
# 14	23100-KHC4-900	BELT DRIVE	27,42 €(23,59 £)
# 15	23200-GCW3-001	FACE ASSY DRIVEN	52,42 €(45,11 £)
# 16	23220-KHC4-900	FACE COMP MOVABLE DRIVEN	47,42 €(40,80 £)
# 17	23225-GCW3-001	PIN ROLLER GUIDE	1,25 €(1,08 £)
# 18	23226-GCW3-001	ROLLER GUIDE	0,83 €(0,71 £)
# 19	23233-LAB4-900	SPRING DRIVEN FACE	6,58 €(5,66 £)
# 20	23237-GCW3-001	COLLAR SPRING	6,67 €(5,74 £)
# 21	23239-GCW3-851	COLLAR SPRING	3,58 €(3,08 £)
# 22	28211-KNBN-901	RATCHET KICK STARTER	8,75 €(7,53 £)
# 23	90202-1G87-C00	NUT SPECIAL (M28)	1,92 €(1,65 £)
# 24	90442-0D44-001	WASHER THRUST (6MM)	0,67 €(0,58 £)
# 25	90454-GBB2-C00	CIRCLIP (6MM)	0,83 €(0,71 £)
# 26	91001-GGA7-C00	BEARING BALL (6901 U)(12X24X6)	10,42 €(8,97 £)
# 27	91103-GAR1-00A	BEARING NEEDLE (17X25X18 WS)	9,58 €(8,24 £)
# 28	91211-GHK8-014	OIL SEAL (34X39X3) - A	5,75 €(4,95 £)
# 29	91351-6B42-000	O-RING (42X40X1, 8)	2,08 €(1,79 £)
# 30	91351-GAR1-001	O-RING (42X38, 5X2)	2,33 €(2,00 £)
# 31	94050-10080	NUT FLANGE (M10X10)	1,42 €(1,22 £)
# 32	94050-12080	NUT FLANGE (M12X11)	1,42 €(1,22 £)
# 33	94520-24000	CIRCLIP IN (24MM)	1,25 €(1,08 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Kymco, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
