TAMBOUR DE FREINS FOR KYMCO METEORIT 125 EURO

230

(230) KY-99-1000

REFERENCE PLUS FABRIQUE PAR KYMCO NE PEUX PLUS ETRE COMMAND&IUML;&IQUEST;

231

(231) 43100-KGG7-832-NJA

PANEL COMP REAR BRAKE (SILVER)

232

(232) 43120-KGG7-305

SHOE ASSY BRAKE

233

(233) 45133-2L40-001

SPRING BRAKE SHOE

234

(234) 43141-KKAK-900

CAM REAR BRAKE

235

(235) 45134-2L50-001

DUST SEAL

236

(236) 90549-1A21-001

WASHER PLAIN (0,50X14,33X21,93)

238

(238) 43410-KKAK-C10-F1S

ARM BRAKE REAR (CHROME)

240

(240) 92101-06036-0B

BOLT HEX (M06X36)

241

(241) 90525-0A01-001

WASHER PLAIN (1,54X6,45X11,90)

242

(242) 94001-06020-0S

NUT HEX (M06)

243

(243) 92811-KKAK-900

BOLT B STPR ARM

244

(244) 43431-KKAK-C10-F1S

ARM REAR BRAKE STOPPER (CHROME)

245

(245) KY-99-1000

REFERENCE PLUS FABRIQUE PAR KYMCO NE PEUX PLUS ETRE COMMAND&IUML;&IQUEST;

246

(246) 94111-08800

WASHER SPRING (2,13X8,46X14,94)

247

(247) 94001-08080-0S

NUT HEX (M08)

248

(248) 94201-20150

PIN SPLIT (2X15MM)

249

(249) 43434-2F86-001

GROMMER WASHER (3,80X10,87X22,09)

250

(250) 90524-KKAK-900

WASHER PLAIN (1,56X8,46X21,88)

251

(251) 94101-08800

WASHER PLAIN (1,59X8,65X17,85)

	Part number	Description	Qty
# 230	KY-99-1000	REFERENCE PLUS FABRIQUE PAR KYMCO NE PEUX PLUS ETRE COMMAND&IUML;&IQUEST;	Not available	0,00 €(0,00 £)
# 231	43100-KGG7-832-NJA	PANEL COMP REAR BRAKE (SILVER)	19,08 €(16,34 £)
# 232	43120-KGG7-305	SHOE ASSY BRAKE	14,08 €(12,06 £)
# 233	45133-2L40-001	SPRING BRAKE SHOE	1,83 €(1,57 £)
# 234	43141-KKAK-900	CAM REAR BRAKE	9,58 €(8,20 £)
# 235	45134-2L50-001	DUST SEAL	1,17 €(1,00 £)
# 236	90549-1A21-001	WASHER PLAIN (0, 50X14, 33X21, 93)	0,67 €(0,57 £)
# 238	43410-KKAK-C10-F1S	ARM BRAKE REAR (CHROME)	7,08 €(6,06 £)
# 240	92101-06036-0B	BOLT HEX (M06X36)	1,92 €(1,64 £)
# 241	90525-0A01-001	WASHER PLAIN (1, 54X6, 45X11, 90)	0,67 €(0,57 £)
# 242	94001-06020-0S	NUT HEX (M06)	0,83 €(0,71 £)
# 243	92811-KKAK-900	BOLT B STPR ARM	3,25 €(2,78 £)
# 244	43431-KKAK-C10-F1S	ARM REAR BRAKE STOPPER (CHROME)	7,08 €(6,06 £)
# 245	KY-99-1000	REFERENCE PLUS FABRIQUE PAR KYMCO NE PEUX PLUS ETRE COMMAND&IUML;&IQUEST;	Not available	0,00 €(0,00 £)
# 246	94111-08800	WASHER SPRING (2, 13X8, 46X14, 94)	1,00 €(0,86 £)
# 247	94001-08080-0S	NUT HEX (M08)	1,42 €(1,22 £)
# 248	94201-20150	PIN SPLIT (2X15MM)	1,42 €(1,22 £)
# 249	43434-2F86-001	GROMMER WASHER (3, 80X10, 87X22, 09)	0,67 €(0,57 £)
# 250	90524-KKAK-900	WASHER PLAIN (1, 56X8, 46X21, 88)	0,67 €(0,57 £)
# 251	94101-08800	WASHER PLAIN (1, 59X8, 65X17, 85)	1,42 €(1,22 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Kymco, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
