CARBURETOR

FAIRINGS FOR KYMCO QUANNON 125 4T EURO III

RIGHT CASING

(1) 64220-LEC8-E00-L9R

WIND SCREEN

(2) 64240-LEC8-E00-N1R

COVER RIGHT FRONT COWL LEFT SIDE (BLACK BRUT)

(3) 64242-LEC8-E00-N1R

COVER LEFT FRONT COWLEFT SIDE (BLACK BRUT)

(4) 6427A-LEC8-E00-EBP

COVER RIGHT LIGHT (RED)

(4) 6427A-LEC8-E00-HXP

COVER RIGHT LIGHT (IVORY WHITE)

(4) 6427A-LEC8-E00-N8P

COVER RIGHT LIGHT (LIGHT SILVER METAL)

(4) 6427A-LEC8-E00-Y5P

COVER RIGHT LIGHT (YELLOW)

(5) 6428A-LEC8-E00-EBP

COVER LEFT LIGHT (RED)

(5) 6428A-LEC8-E00-HXP

COVER LEFT LIGHT (IVORY WHITE)

(5) 6428A-LEC8-E00-N8P

COVER LEFT LIGHT (LIGHT SILVER METAL)

(5) 6428A-LEC8-E00-Y5P

COVER LEFT LIGHT (YELLOW)

(6) 64301-LEC8-E00-EBP

COVER FRONT (RED)

(6) 64301-LEC8-E00-HXP

COVER FRONT (IVORY WHITE)

(6) 64301-LEC8-E00-N8P

COVER FRONT (LIGHT SILVER METAL)

(6) 64301-LEC8-E00-Y5P

COVER FRONT (YELLOW)

(7) 64302-LEC8-E00-N1R

COVER FRONT LOW (BLACK BRUT)

(8) 64331-LEC8-E00-M2S

GRILL RIGHT SIDE (GALVANIZED)

(9) 6433A-LEC8-E00-N1P

COWL RIGHT FRONT LOWER ASSY (SHINY BLACK)

(10) 64341-LEC8-E00-M2S

GRILLE DE FLANC GAUCHE (TEINTE GALVANISE)

(11) 6434A-LEC8-E00-N1P

COWL LEFT FRONT LOWER ASSY (SHINY BLACK)

(12) 6440A-LEC8-E00-N1P

COWL FRONT UNDER ASSY (SHINY BLACK)

(12) 6440A-LEC8-E00-NHP

COWL FRONT UNDER ASSY (CHARCOAL)

(13) 77232-KCAC-C00

SET SPRING LOCK KEY

(14) 77239-GFY6-C00

CATCH ASSY SEAT

(15) 81300-LEC8-E00-EBP

GRIP COMP REAR (RED)

(15) 81300-LEC8-E00-HXP

GRIP COMP REAR (IVORY WHITE)

(15) 81300-LEC8-E00-N8P

GRIP COMP REAR (LIGHT SILVER METAL)

(15) 81300-LEC8-E00-NEP

GRIP COMP REAR (DARK MAT BLACK)

(15) 81300-LEC8-E00-Y5P

GRIP COMP REAR (YELLOW)

(16) 83500-LEC8-E00-EBP

COVER RIGHT BODY (RED)

(16) 83500-LEC8-E00-HXP

COVER RIGHT BODY (IVORY WHITE)

(16) 83500-LEC8-E00-N8P

CARENAGE ARRIERE DROIT (ARGENT CLAIR METAL)

(16) 83500-LEC8-E00-Y5P

COVER RIGHT BODY (YELLOW)

(17) 83520-LEC8-E00-HJP

COVER RIGHT SIDE (CHARCOAL)

(18) 83600-LEC8-E00-EBP

COVER LEFT BODY (RED)

(18) 83600-LEC8-E00-HXP

COVER LEFT BODY (IVORY WHITE)

(18) 83600-LEC8-E00-Y5P

COVER LEFT BODY (YELLOW)

(19) 83620-LEC8-E00-HJP

COVER LEFT SIDE (CHARCOAL)

(20) 90102-LEC8-001

SCREW PAN (M05X17)(BLACK)

(21) 90111-LEC8-E00

BOLT (M06X14)(BLACK)

(22) 90106-LEC8-900

SOCKET BOLT (M08X42)(SILVER)

(23) 90652-LEC8-E00

CLIP MUDGUARD

(24) 90652-LCA4-E00

CLIP MUDGUARD

(25) 93404-06016-06

BOLT HEX (M06X16)(BLACK)

(26) 93903-34360

SCREW TAPPING (M04X12)(BLACK)

(27) 93903-KEB7-900-06

SCREW TAPPING (M04X12)(BLACK)

(28) 94050-06060

NUT (M06)

	Part number	Description	Qty
# 1	64220-LEC8-E00-L9R	WIND SCREEN	16,58 €(14,25 £)
# 2	64240-LEC8-E00-N1R	COVER RIGHT FRONT COWL LEFT SIDE (BLACK BRUT)	8,25 €(7,09 £)
# 3	64242-LEC8-E00-N1R	COVER LEFT FRONT COWLEFT SIDE (BLACK BRUT)	5,75 €(4,94 £)
# 4	6427A-LEC8-E00-EBP	COVER RIGHT LIGHT (RED)	56,58 €(48,63 £)
# 4	6427A-LEC8-E00-HXP	COVER RIGHT LIGHT (IVORY WHITE)	56,58 €(48,63 £)
# 4	6427A-LEC8-E00-N8P	COVER RIGHT LIGHT (LIGHT SILVER METAL)	56,58 €(48,63 £)
# 4	6427A-LEC8-E00-Y5P	COVER RIGHT LIGHT (YELLOW)	56,58 €(48,63 £)
# 5	6428A-LEC8-E00-EBP	COVER LEFT LIGHT (RED)	56,58 €(48,63 £)
# 5	6428A-LEC8-E00-HXP	COVER LEFT LIGHT (IVORY WHITE)	56,58 €(48,63 £)
# 5	6428A-LEC8-E00-N8P	COVER LEFT LIGHT (LIGHT SILVER METAL)	56,58 €(48,63 £)
# 5	6428A-LEC8-E00-Y5P	COVER LEFT LIGHT (YELLOW)	56,58 €(48,63 £)
# 6	64301-LEC8-E00-EBP	COVER FRONT (RED)	43,25 €(37,17 £)
# 6	64301-LEC8-E00-HXP	COVER FRONT (IVORY WHITE)	43,25 €(37,17 £)
# 6	64301-LEC8-E00-N8P	COVER FRONT (LIGHT SILVER METAL)	43,25 €(37,17 £)
# 6	64301-LEC8-E00-Y5P	COVER FRONT (YELLOW)	43,25 €(37,17 £)
# 7	64302-LEC8-E00-N1R	COVER FRONT LOW (BLACK BRUT)	6,58 €(5,66 £)
# 8	64331-LEC8-E00-M2S	GRILL RIGHT SIDE (GALVANIZED)	14,08 €(12,10 £)
# 9	6433A-LEC8-E00-N1P	COWL RIGHT FRONT LOWER ASSY (SHINY BLACK)	95,75 €(82,29 £)
# 10	64341-LEC8-E00-M2S	GRILLE DE FLANC GAUCHE (TEINTE GALVANISE)	Not available	0,00 €(0,00 £)
# 11	6434A-LEC8-E00-N1P	COWL LEFT FRONT LOWER ASSY (SHINY BLACK)	95,75 €(82,29 £)
# 12	6440A-LEC8-E00-N1P	COWL FRONT UNDER ASSY (SHINY BLACK)	87,42 €(75,13 £)
# 12	6440A-LEC8-E00-NHP	COWL FRONT UNDER ASSY (CHARCOAL)	87,42 €(75,13 £)
# 13	77232-KCAC-C00	SET SPRING LOCK KEY	3,58 €(3,08 £)
# 14	77239-GFY6-C00	CATCH ASSY SEAT	15,75 €(13,54 £)
# 15	81300-LEC8-E00-EBP	GRIP COMP REAR (RED)	43,25 €(37,17 £)
# 15	81300-LEC8-E00-HXP	GRIP COMP REAR (IVORY WHITE)	43,25 €(37,17 £)
# 15	81300-LEC8-E00-N8P	GRIP COMP REAR (LIGHT SILVER METAL)	43,25 €(37,17 £)
# 15	81300-LEC8-E00-NEP	GRIP COMP REAR (DARK MAT BLACK)	43,25 €(37,17 £)
# 15	81300-LEC8-E00-Y5P	GRIP COMP REAR (YELLOW)	43,25 €(37,17 £)
# 16	83500-LEC8-E00-EBP	COVER RIGHT BODY (RED)	95,75 €(82,29 £)
# 16	83500-LEC8-E00-HXP	COVER RIGHT BODY (IVORY WHITE)	95,75 €(82,29 £)
# 16	83500-LEC8-E00-Y5P	COVER RIGHT BODY (YELLOW)	95,75 €(82,29 £)
# 16	83500-LEC8-E00-N8P	CARENAGE ARRIERE DROIT (ARGENT CLAIR METAL)	Not available	0,00 €(0,00 £)
# 17	83520-LEC8-E00-HJP	COVER RIGHT SIDE (CHARCOAL)	38,25 €(32,87 £)
# 18	83600-LEC8-E00-EBP	COVER LEFT BODY (RED)	95,75 €(82,29 £)
# 18	83600-LEC8-E00-HXP	COVER LEFT BODY (IVORY WHITE)	95,75 €(82,29 £)
# 18	83600-LEC8-E00-Y5P	COVER LEFT BODY (YELLOW)	95,75 €(82,29 £)
# 19	83620-LEC8-E00-HJP	COVER LEFT SIDE (CHARCOAL)	43,25 €(37,17 £)
# 20	90102-LEC8-001	SCREW PAN (M05X17)(BLACK)	Not available	0,00 €(0,00 £)
# 21	90111-LEC8-E00	BOLT (M06X14)(BLACK)	2,08 €(1,79 £)
# 22	90106-LEC8-900	SOCKET BOLT (M08X42)(SILVER)	4,75 €(4,08 £)
# 23	90652-LEC8-E00	CLIP MUDGUARD	1,25 €(1,07 £)
# 24	90652-LCA4-E00	CLIP MUDGUARD	1,25 €(1,07 £)
# 25	93404-06016-06	BOLT HEX (M06X16)(BLACK)	1,33 €(1,14 £)
# 26	93903-34360	SCREW TAPPING (M04X12)(BLACK)	1,25 €(1,07 £)		Special offer 1,50 €(1,29 £)
# 27	93903-KEB7-900-06	SCREW TAPPING (M04X12)(BLACK)	1,25 €(1,07 £)
# 28	94050-06060	NUT (M06)	1,42 €(1,22 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FAIRINGS of your Kymco QUANNON 125 4T EURO III of QUANNON. Let us know if you have any questions.
