CRANKSHAFT / PISTON

TIMING FOR KYMCO ZING 125 4T

SPEEDOMETER

(D) 14423-KBE2-982

SHAFT CAM GEAR

(A) 14751-3D24-C00

RESSORT EXTERIEUR DE SOUPAPE

(B) 14761-3D24-C00

RESSORT INTERIEUR DE SOUPAPE

(E) 91318-5L90-001

O-RING (25X20X2,5)

(30) 14711-3C83-001

VALVE INLET

(31) 14721-3C83-001

VALVE EXHAUST

(32) 14775-1G07-C00

SEAT VALVE SPRING OUTER

(33) 14776-1G07-C00

SIEGE DE RESSORT DE SOUPAPE INTERIEUR

(34) 12208-4C13-C00

SEAL VALVE STEM

(37) 14771-1G07-C00

SEAT VALVE SPRING

(38) 14781-1G07-021

COTTER VALVE

(39) 90012-4E15-001

SCREW TAPPET ADJUSTING

(40) 90206-2L50-001

NUT TAPPET ADJUSTING

(41) 14400-3G97-0210

CULBUTEUR

(42) 90442-0H28-001

WASHER SEALING (2,09X8,59X17,85)

(43) 90126-2B92-001

VIS DE FIXATION CULBUTEURS

(44) 12215-3G97-021

GUIDE DE TIGE DE CULBUTEURS

(46) 90444-3G97-001

WASHER WAVE (0,42,12,25X21,05)

(47) 14421-3G97-001

FOLLOWER CAM

(49) 91333-5G67-011

JOINT TORIQUE 20X17X2,5

(50) 90428-9H58-C00

WASHER THRUST (0,97X14,00X23,69)

(52) 14425-KGG7-001

SPRING CAM SHAFT

(53) 14426-KBE2-981

PLATE BEARING STOPPER

(54) 96001-06012-06

BOLT FLANGE (M06X12)(BLACK)

	Part number	Description	Qty
# D	14423-KBE2-982	SHAFT CAM GEAR	7,92 €(6,76 £)
# E	91318-5L90-001	O-RING (25X20X2, 5)	1,25 €(1,07 £)
# A	14751-3D24-C00	RESSORT EXTERIEUR DE SOUPAPE	Not available	0,00 €(0,00 £)
# B	14761-3D24-C00	RESSORT INTERIEUR DE SOUPAPE	Not available	0,00 €(0,00 £)
# 30	14711-3C83-001	VALVE INLET	8,75 €(7,47 £)
# 31	14721-3C83-001	VALVE EXHAUST	14,08 €(12,02 £)
# 32	14775-1G07-C00	SEAT VALVE SPRING OUTER	1,25 €(1,07 £)
# 33	14776-1G07-C00	SIEGE DE RESSORT DE SOUPAPE INTERIEUR	Not available	0,00 €(0,00 £)
# 34	12208-4C13-C00	SEAL VALVE STEM	3,25 €(2,78 £)
# 37	14771-1G07-C00	SEAT VALVE SPRING	3,92 €(3,35 £)
# 38	14781-1G07-021	COTTER VALVE	1,92 €(1,64 £)
# 39	90012-4E15-001	SCREW TAPPET ADJUSTING	2,75 €(2,35 £)
# 40	90206-2L50-001	NUT TAPPET ADJUSTING	1,92 €(1,64 £)
# 41	14400-3G97-0210	CULBUTEUR	Not available	0,00 €(0,00 £)
# 42	90442-0H28-001	WASHER SEALING (2, 09X8, 59X17, 85)	1,25 €(1,07 £)
# 43	90126-2B92-001	VIS DE FIXATION CULBUTEURS	Not available	0,00 €(0,00 £)
# 44	12215-3G97-021	GUIDE DE TIGE DE CULBUTEURS	Not available	0,00 €(0,00 £)
# 46	90444-3G97-001	WASHER WAVE (0, 42, 12, 25X21, 05)	0,58 €(0,50 £)
# 47	14421-3G97-001	FOLLOWER CAM	19,08 €(16,29 £)
# 49	91333-5G67-011	JOINT TORIQUE 20X17X2, 5	Not available	0,00 €(0,00 £)
# 50	90428-9H58-C00	WASHER THRUST (0, 97X14, 00X23, 69)	1,50 €(1,28 £)
# 52	14425-KGG7-001	SPRING CAM SHAFT	1,25 €(1,07 £)
# 53	14426-KBE2-981	PLATE BEARING STOPPER	0,58 €(0,50 £)
# 54	96001-06012-06	BOLT FLANGE (M06X12)(BLACK)	1,17 €(1,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the TIMING of your Kymco ZING 125 4T of ZING. Let us know if you have any questions.
