ELECTRICAL EQUIPMENT / LOCK SET

FRAME / ENGINE MOUNT FOR KYMCO LIKE 150I ABS EURO 4

ANTI POLLUTION

5071A

(5071A) 5071A-ACC1-E10

BAR COMP RIGHT STEP

5071B

(5071B) 5071B-ACC1-E10

BAR COMP LEFT STEP

11345

(11345) 11345-LEA7-E00

DUCT LEFT COVER

11346

(11346) 11346-GFY6-901

BAND LEFT COVER DUCT

17582

(17582) 17582-ACC1-E10-N1R

HEAT GUARD FUEL TANK (BLACK BRUT)

50100

(50100) 50100-AEA7-E10

BODY COMP FRAME

50301

(50301) 50301-KGN7-671

RACE STEERING TOP CONE

50302

(50302) 50302-2H68-C00

RACE STEERING BOTTOM CONE

50320

(50320) 50320-ACC1-E10

STAY REAR FENDER

50350

(50350) 50350-LKE6-C00

ENGINE HANGER ASSY

50505

(50505) 50505-LEJ2-E11

STOPPER RUBBER MAIN STAND

50611

(50611) 50611-ACC1-E10

STAY RIGHT FLOOR PANEL

50612

(50612) 50612-ACC1-E10

STAY LEFT FLOOR PANEL

50613

(50613) 50613-ACC1-E10-N1R

COVER UNDER (BLACK BRUT)

50616

(50616) 50616-ACC1-E10

STAY RIGHT FRONT FENDER

50623

(50623) 50623-ACC1-E10-N1R

COVER UNDER (BLACK BRUT)

64315

(64315) 64315-ACC1-E10

BRACKET FRONT COVER

83552

(83552) 83552-ACC1-E10

GROMMER WASHER

85104

(85104) 85104-ALJ8-E10

RUBBER STOPPER

90105

(90105) 90105-KHC4-900

SQUARE BOLT (M10X50)

90106

(90106) 90106-KFAF-900

SOCKET BOLT (M08X32)(SILVER)

90107

(90107) 90107-KUDU-900

BOLT FLANGE (M10X188)(GOLD)

90304

(90304) 90304-PUA3-B50

NUT CAP M10

90651

(90651) 90651-ALH3-700

BAND INLET-PIPE

93404

(93404) 93404-06012-07

BOLT HEX (M06X12)(BLACK)

93903

(93903) 93903-25220

VIS TARAUDEUSE M05X12

94050-06070

(94050-06070) 94050-06070-G

NUT (M06)

94050-06080

(94050-06080) 94050-06080

NUT (M06)

95701-06012

(95701-06012) 95701-06012-07

BOLT FLANGE (M06X12)(BLACK)

95701-08016

(95701-08016) 95701-08016-07

BOLT FLANGE (M08X16)(BLACK)

96001

(96001) 96001-06032-07

BOLT FLANGE (M06X32)(BLACK)

	Part number	Description	Qty
# 5071A	5071A-ACC1-E10	BAR COMP RIGHT STEP	19,92 €(17,20 £)
# 5071B	5071B-ACC1-E10	BAR COMP LEFT STEP	19,92 €(17,20 £)
# 11345	11345-LEA7-E00	DUCT LEFT COVER	11,25 €(9,71 £)
# 11346	11346-GFY6-901	BAND LEFT COVER DUCT	3,75 €(3,24 £)
# 17582	17582-ACC1-E10-N1R	HEAT GUARD FUEL TANK (BLACK BRUT)	5,42 €(4,68 £)
# 50100	50100-AEA7-E10	BODY COMP FRAME	325,00 €(280,57 £)
# 50301	50301-KGN7-671	RACE STEERING TOP CONE	5,75 €(4,96 £)
# 50302	50302-2H68-C00	RACE STEERING BOTTOM CONE	5,75 €(4,96 £)
# 50320	50320-ACC1-E10	STAY REAR FENDER	12,42 €(10,72 £)
# 50350	50350-LKE6-C00	ENGINE HANGER ASSY	81,58 €(70,43 £)
# 50505	50505-LEJ2-E11	STOPPER RUBBER MAIN STAND	1,50 €(1,29 £)
# 50611	50611-ACC1-E10	STAY RIGHT FLOOR PANEL	12,42 €(10,72 £)
# 50612	50612-ACC1-E10	STAY LEFT FLOOR PANEL	12,42 €(10,72 £)
# 50613	50613-ACC1-E10-N1R	COVER UNDER (BLACK BRUT)	21,58 €(18,63 £)
# 50616	50616-ACC1-E10	STAY RIGHT FRONT FENDER	10,42 €(9,00 £)
# 50623	50623-ACC1-E10-N1R	COVER UNDER (BLACK BRUT)	5,75 €(4,96 £)
# 64315	64315-ACC1-E10	BRACKET FRONT COVER	24,92 €(21,51 £)
# 83552	83552-ACC1-E10	GROMMER WASHER	1,25 €(1,08 £)
# 85104	85104-ALJ8-E10	RUBBER STOPPER	1,92 €(1,66 £)
# 90105	90105-KHC4-900	SQUARE BOLT (M10X50)	4,75 €(4,10 £)
# 90106	90106-KFAF-900	SOCKET BOLT (M08X32)(SILVER)	3,25 €(2,81 £)
# 90107	90107-KUDU-900	BOLT FLANGE (M10X188)(GOLD)	4,75 €(4,10 £)
# 90304	90304-PUA3-B50	NUT CAP M10	1,25 €(1,08 £)
# 90651	90651-ALH3-700	BAND INLET-PIPE	0,83 €(0,72 £)
# 93404	93404-06012-07	BOLT HEX (M06X12)(BLACK)	1,33 €(1,15 £)
# 93903	93903-25220	VIS TARAUDEUSE M05X12	Not available	0,00 €(0,00 £)
# 94050-06070	94050-06070-G	NUT (M06)	1,42 €(1,23 £)
# 94050-06080	94050-06080	NUT (M06)	1,42 €(1,23 £)
# 95701-06012	95701-06012-07	BOLT FLANGE (M06X12)(BLACK)	1,42 €(1,23 £)
# 95701-08016	95701-08016-07	BOLT FLANGE (M08X16)(BLACK)	0,92 €(0,79 £)
# 96001	96001-06032-07	BOLT FLANGE (M06X32)(BLACK)	2,33 €(2,01 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
