CARBURATION FOR KYMCO KRV 200 4T EURO 5

CARENAGES ARRIERES

16056

(16056) 16056-ACD5-E00

LEVER ASSY THROTTLE

16066

(16066) 16066-ACD5-E00

PLATE VALVE ISC

16068

(16068) 16068-ACD5-E00

PLATE WIRE FIXED

16074

(16074) 16074-KEC3-900

WASHER IDLE SCREW (0,59X3,03X4,97)

16100

(16100) 16100-AEE2-C00

THROTTLE BODY ASSY

16113

(16113) 16113-PTA1-800

SCREW IDLE ADJUST

16122

(16122) 16122-KEC3-900

O-RING

16134

(16134) 16134-ACD5-E00

SPRING THROTTLE SHAFT

16137

(16137) 16137-ACD5-E00

COLLAR LEVER

16138

(16138) 16138-KEC3-900

SPRING THROTTLE ADJUST SCREW

16154

(16154) 16154-LGM5-900

SCREW IDLE ADJUST

16195

(16195) 16195-KEC3-900

BALL STEEL 2 1MM

39700

(39700) 39700-ACD5-E03

REED VALVE ASSY

39800

(39800) 39800-ACD5-E00

PPTS VALVE ASSY

93891

(93891) 93891-04014-06

SCREW PAN (M04X14)(BLACK)

93892

(93892) 93892-05010-06

SCREW PAN (M05X10)(BLACK)

94030

(94030) 94030-PTA1-800

NUT HEX (M05)

94050

(94050) 94050-06080

NUT (M06)

94111

(94111) 94111-06800

WASHER SPRING (1,70X6,52X11,64)

	Part number	Description	Qty
# 16056	16056-ACD5-E00	LEVER ASSY THROTTLE	3,58 €(3,07 £)
# 16066	16066-ACD5-E00	PLATE VALVE ISC	1,25 €(1,07 £)
# 16068	16068-ACD5-E00	PLATE WIRE FIXED	1,50 €(1,28 £)
# 16074	16074-KEC3-900	WASHER IDLE SCREW (0, 59X3, 03X4, 97)	0,67 €(0,57 £)
# 16100	16100-AEE2-C00	THROTTLE BODY ASSY	174,92 €(149,81 £)
# 16113	16113-PTA1-800	SCREW IDLE ADJUST	1,50 €(1,28 £)
# 16122	16122-KEC3-900	O-RING	0,92 €(0,79 £)
# 16134	16134-ACD5-E00	SPRING THROTTLE SHAFT	1,25 €(1,07 £)
# 16137	16137-ACD5-E00	COLLAR LEVER	1,25 €(1,07 £)
# 16138	16138-KEC3-900	SPRING THROTTLE ADJUST SCREW	1,42 €(1,22 £)
# 16154	16154-LGM5-900	SCREW IDLE ADJUST	3,92 €(3,36 £)
# 16195	16195-KEC3-900	BALL STEEL 2 1MM	0,92 €(0,79 £)
# 39700	39700-ACD5-E03	REED VALVE ASSY	53,25 €(45,60 £)
# 39800	39800-ACD5-E00	PPTS VALVE ASSY	53,25 €(45,60 £)
# 93891	93891-04014-06	SCREW PAN (M04X14)(BLACK)	2,67 €(2,29 £)
# 93892	93892-05010-06	SCREW PAN (M05X10)(BLACK)	1,83 €(1,57 £)
# 94030	94030-PTA1-800	NUT HEX (M05)	1,25 €(1,07 £)
# 94050	94050-06080	NUT (M06)	1,42 €(1,22 £)
# 94111	94111-06800	WASHER SPRING (1, 70X6, 52X11, 64)	0,67 €(0,57 £)
