ENGINE CASINGS FOR KYMCO K XCT 300I ABS

CYLINDER HEAD / COVER

1110A

(1110A) 1110A-LEA7-E05

CRANK CASE ASSEMBLY

1122A

(1122A) 1122A-LEA7-E00

TUBE BREATHER MISSION

1134A

(1134A) 1134A-LEA7-E00-D1U

GRUPPO COPERCHIO CARTER SX

1134B

(1134B) 1134B-LEA7-E00-D1U

COP. CARTER SX

11103

(11103) 11103-KHE7-900

RUBBER BUSH ENGINE HANGER

11203

(11203) 11203-LBA2-E00

RUB BUSH LEFT CASE

11340

(11340) 11340-LEA7-E01

CARTER SX

11341

(11341) 11341-LEA7-E01

COVER LEFT CRANK CASE

11344

(11344) 11344-LEA7-E00

FOAM TEXTURE

11345

(11345) 11345-LEA7-E00

DUCT LEFT COVER

11346

(11346) 11346-GFY6-901

BAND LEFT COVER DUCT

11350

(11350) 11350-LEA7-E00

ELEMENT COMP LEFT COVER

11395

(11395) 11395-LEA7-E00

GASKET LEFT COVER

13314

(13314) 13314-LEA7-E0A

BEARING CRANKSHAFT A (RED)(1,995-1,998)

(13314) 13314-LEA7-E0B

BEARING CRANKSHAFT B (GREEN)(1,991-1,994)

(13314) 13314-LEA7-E0C

BEARING CRANKSHAFT C (BLACK)(1,986-1,990)

15161

(15161) 15161-PUA5-E00

HOLE CAP TAPPET ADJUSTING

15200

(15200) 15200-KED9-900

OIL RELIEF VALVE ASSY

15421

(15421) 15421-LEA7-E00

SCREEN OIL FILTER

(15421) 15421-LEA7-E05

SCREEN OIL FILTER

18291

(18291) 18291-KKC4-900

COLLAR

18293

(18293) 18293-KKC4-900

PACKING PROTECTOR (7,69X8,83X14,28)

19613

(19613) 19613-GFY6-901

CLAMPER STARTER MOTOR CORD

32105

(32105) 32105-LLJ3-E00

SUB HARNESS

35500

(35500) 35500-KED9-900

SWITCH ASSY OIL PRESSURE

50504

(50504) 50504-LEA7-E05

STOPPER RUBBER MAIN STAND

90032

(90032) 90032-LEA7-E00

BOLT STUD (M10X180)

90474

(90474) 90474-3C33-001

WASHER-DRAIN PLUG (8MM)

90701

(90701) 90701-9E65-001

PIN DOWEL (10X16)

91005

(91005) 91005-LBA7-900

BEARING BALL (6005 LLU)(25X47X12)

91009

(91009) 91009-KHE7-900

BEARING BALL (6205 LLU)(31X65X17)

91201

(91201) 91201-LEA7-E00

OIL SEAL (35X50X7)

91255

(91255) 91255-KHE7-900

OIL SEAL (34X52X7)

91301

(91301) 91301-2L00-001

O-RING (6,8X1,9)

91306

(91306) 91306-PUA5-E00

O-RING (16X13X1,5)

91307

(91307) 91307-PUA5-E00

O-RING (22X18X2)

(91313) 91313-KED9-900

O-RING (18X15,5X1,5)

91552

(91552) 91552-LEA7-E00

COLLAR (10,5MM)

92101

(92101) 92101-05008-0A

BOLT HEX (M05X08)(GOLD)

94050

(94050) 94050-10060

NUT FLANGE (M12X13)

94301

(94301) 94301-10160

PIN DOWEL (10X16)

94520

(94520) 94520-47000

CIRCLIP IN (47MM)

95002

(95002) 95002-50000

CLIP (9MM)

95701

(95701) 95701-08012-08

BOLT FLANGE (M08X12)(GOLD)

96001

(96001) 96001-06020-06

BOLT FLANGE (M06X20)(BLACK)

(96001) 96001-06030-08

VIS EPAULEE A TETE HEXAGONALE DE 08 (M06X30/19 OR)

(96001) 96001-06070-08

VITE 6X 70 ZG FLANGIATA ESAG.

(96001) 96001-06080-08

BOLT FLANGE (M06X80)(GOLD)

96100

(96100) 96100-63020-00

BEARING BALL (6302)(15X43X13)

	Part number	Description	Qty
# 1110A	1110A-LEA7-E05	CRANK CASE ASSEMBLY	376,58 €(321,62 £)
# 1122A	1122A-LEA7-E00	TUBE BREATHER MISSION	3,58 €(3,06 £)
# 1134A	1134A-LEA7-E00-D1U	GRUPPO COPERCHIO CARTER SX	Not available	0,00 €(0,00 £)
# 1134B	1134B-LEA7-E00-D1U	COP. CARTER SX	Not available	0,00 €(0,00 £)
# 11103	11103-KHE7-900	RUBBER BUSH ENGINE HANGER	4,75 €(4,06 £)
# 11203	11203-LBA2-E00	RUB BUSH LEFT CASE	4,33 €(3,70 £)
# 11340	11340-LEA7-E01	CARTER SX	Not available	0,00 €(0,00 £)
# 11341	11341-LEA7-E01	COVER LEFT CRANK CASE	141,58 €(120,92 £)
# 11344	11344-LEA7-E00	FOAM TEXTURE	34,92 €(29,82 £)
# 11345	11345-LEA7-E00	DUCT LEFT COVER	11,25 €(9,61 £)
# 11346	11346-GFY6-901	BAND LEFT COVER DUCT	3,75 €(3,20 £)
# 11350	11350-LEA7-E00	ELEMENT COMP LEFT COVER	12,42 €(10,61 £)
# 11395	11395-LEA7-E00	GASKET LEFT COVER	19,08 €(16,30 £)
# 13314	13314-LEA7-E0A	BEARING CRANKSHAFT A (RED)(1, 995-1, 998)	12,42 €(10,61 £)
# 13314	13314-LEA7-E0B	BEARING CRANKSHAFT B (GREEN)(1, 991-1, 994)	12,42 €(10,61 £)
# 13314	13314-LEA7-E0C	BEARING CRANKSHAFT C (BLACK)(1, 986-1, 990)	12,42 €(10,61 £)
# 15161	15161-PUA5-E00	HOLE CAP TAPPET ADJUSTING	8,75 €(7,47 £)
# 15200	15200-KED9-900	OIL RELIEF VALVE ASSY	31,58 €(26,97 £)
# 15421	15421-LEA7-E00	SCREEN OIL FILTER	11,25 €(9,61 £)
# 15421	15421-LEA7-E05	SCREEN OIL FILTER	11,25 €(9,61 £)
# 18291	18291-KKC4-900	COLLAR	1,67 €(1,43 £)
# 18293	18293-KKC4-900	PACKING PROTECTOR (7, 69X8, 83X14, 28)	2,08 €(1,78 £)
# 19613	19613-GFY6-901	CLAMPER STARTER MOTOR CORD	0,92 €(0,79 £)
# 32105	32105-LLJ3-E00	SUB HARNESS	6,00 €(5,12 £)
# 35500	35500-KED9-900	SWITCH ASSY OIL PRESSURE	19,92 €(17,01 £)
# 50504	50504-LEA7-E05	STOPPER RUBBER MAIN STAND	6,25 €(5,34 £)
# 90032	90032-LEA7-E00	BOLT STUD (M10X180)	11,25 €(9,61 £)
# 90474	90474-3C33-001	WASHER-DRAIN PLUG (8MM)	0,58 €(0,50 £)
# 90701	90701-9E65-001	PIN DOWEL (10X16)	1,17 €(1,00 £)
# 91005	91005-LBA7-900	BEARING BALL (6005 LLU)(25X47X12)	15,75 €(13,45 £)
# 91009	91009-KHE7-900	BEARING BALL (6205 LLU)(31X65X17)	13,25 €(11,32 £)
# 91201	91201-LEA7-E00	OIL SEAL (35X50X7)	8,75 €(7,47 £)
# 91255	91255-KHE7-900	OIL SEAL (34X52X7)	9,58 €(8,18 £)
# 91301	91301-2L00-001	O-RING (6, 8X1, 9)	0,92 €(0,79 £)
# 91306	91306-PUA5-E00	O-RING (16X13X1, 5)	1,83 €(1,56 £)
# 91307	91307-PUA5-E00	O-RING (22X18X2)	1,67 €(1,43 £)
# 91313	91313-KED9-900	O-RING (18X15, 5X1, 5)	1,00 €(0,85 £)
# 91552	91552-LEA7-E00	COLLAR (10, 5MM)	2,50 €(2,14 £)
# 92101	92101-05008-0A	BOLT HEX (M05X08)(GOLD)	1,17 €(1,00 £)
# 94050	94050-10060	NUT FLANGE (M12X13)	2,42 €(2,07 £)
# 94301	94301-10160	PIN DOWEL (10X16)	1,25 €(1,07 £)
# 94520	94520-47000	CIRCLIP IN (47MM)	5,42 €(4,63 £)
# 95002	95002-50000	CLIP (9MM)	1,17 €(1,00 £)
# 95701	95701-08012-08	BOLT FLANGE (M08X12)(GOLD)	1,50 €(1,28 £)
# 96001	96001-06020-06	BOLT FLANGE (M06X20)(BLACK)	1,42 €(1,21 £)
# 96001	96001-06070-08	VITE 6X 70 ZG FLANGIATA ESAG.	Not available	0,00 €(0,00 £)
# 96001	96001-06080-08	BOLT FLANGE (M06X80)(GOLD)	2,67 €(2,28 £)
# 96001	96001-06030-08	VIS EPAULEE A TETE HEXAGONALE DE 08 (M06X30/19 OR)	Not available	0,00 €(0,00 £)
# 96100	96100-63020-00	BEARING BALL (6302)(15X43X13)	7,92 €(6,76 £)
