RIGHT CASING

CRANKCASE / OIL PUMP FOR KYMCO MXER 50 2T EURO II

FRAME

(1) KY-99-1000

REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)

(2) 11102-1G87-004

RUBBER BUSH ENGINE HANGER

(3) KY-99-1000

REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)

(4) 11344-LLB1-900

DUCT B LEFT COVER

(5) 11203-GGC7-W10

UNDER RUBBER BUSH REAR CUSHION

(6) 11204-KNBN-901

JOINT COMP BREATHER TUBE

(7) 11205-GHAH-C00

BUSH (8X12X8)

(8) 11205-KNBN-901

BUSH MAIN STAND

(9) 11208-GKAK-C00

CLAMPER CARB DRAIN

(10) 14100-GKAK-921

VALVE COMP REED

(11) 15115-KNBN-921

CLAMP OIL TUBE

(12) 15110-KNBN-901

PLATE COMP OIL PUMP SET

(13) 15115-KNBN-921

CLAMP OIL TUBE

(14) 1552A-KNBN-950

TUBE ASSY OIL PASS

(15) 1621A-GKAK-901

INSULATOR CARB ASSY (CLASS A)

(16) 17100-LLJ1-900

PIPE ASSY INLET

(17) 17111-LBD3-900

GASKET INLET PIPE A

(18) 17112-LBD3-900

GASKET INLET PIPE B

(19) 90521-GFY6-C00

WASHER-DRAIN PLUG (10MM)

(20) 91001-GLW0-90A

BEARING BALL (SC04A50)(20X52X12)- VILO DROIT

(21) 96100-62030-00

BEARING BALL (6203)(17X40X12)

(22) 96100-62010-00

BEARING BALL (6201)(12X32X10)

(23) 91006-KNBN-901

BEARING BALL (SC05A97)(25X56X12) - VILO GAUCHE

(24) 91201-KNBN-C00

OIL SEAL (15,6X25,5X7)

(25) 91202-KNBN-C00

OIL SEAL (20X31X7)

(26) 91204-KNBN-C00

OIL SEAL (17X30X6)

(27) 91305-LEH6-E00

O-RING (19,8X1,9)

(29) 94050-06080

NUT (M06)

(30) 94301-10200

PIN DOWEL (10X20)

(31) 95002-02650

CLIP (6,5MM)

(32) 95801-08012-08

VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)

(33) 95701-08040-08

VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X40/22 OR)

(34) 90131-LEB1-900

BOLT FLANGE (M08X35)(BLACK)

(35) 96001-06022-06

BOLT FLANGE (M06X22)(BLACK)

(36) 96001-06032-06

BOLT FLANGE (M06X32)(BLACK)

(37) 96001-06045-06

BOLT FLANGE (M06X45)(BLACK)

(38) 96001-06055-06

BOLT FLANGE (M06X55)(BLACK)

(39) 96100-62030-00

BEARING BALL (6203)(17X40X12)

	Part number	Description	Qty
# 1	KY-99-1000	REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)	Not available	0,00 €(0,00 £)
# 2	11102-1G87-004	RUBBER BUSH ENGINE HANGER	Unit Price Excl Tax 4,75 €(3,98 £)
# 3	KY-99-1000	REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)	Not available	0,00 €(0,00 £)
# 4	11344-LLB1-900	DUCT B LEFT COVER	Unit Price Excl Tax 17,42 €(14,59 £)
# 5	11203-GGC7-W10	UNDER RUBBER BUSH REAR CUSHION	Unit Price Excl Tax 2,92 €(2,45 £)
# 6	11204-KNBN-901	JOINT COMP BREATHER TUBE	Unit Price Excl Tax 2,67 €(2,24 £)
# 7	11205-GHAH-C00	BUSH (8X12X8)	Unit Price Excl Tax 1,50 €(1,26 £)
# 8	11205-KNBN-901	BUSH MAIN STAND	Unit Price Excl Tax 2,92 €(2,45 £)
# 9	11208-GKAK-C00	CLAMPER CARB DRAIN	Unit Price Excl Tax 1,17 €(0,98 £)
# 10	14100-GKAK-921	VALVE COMP REED	Unit Price Excl Tax 20,75 €(17,38 £)
# 11	15115-KNBN-921	CLAMP OIL TUBE	Unit Price Excl Tax 1,25 €(1,05 £)
# 12	15110-KNBN-901	PLATE COMP OIL PUMP SET	Unit Price Excl Tax 6,67 €(5,59 £)
# 13	15115-KNBN-921	CLAMP OIL TUBE	Unit Price Excl Tax 1,25 €(1,05 £)
# 14	1552A-KNBN-950	TUBE ASSY OIL PASS	Unit Price Excl Tax 4,75 €(3,98 £)
# 15	1621A-GKAK-901	INSULATOR CARB ASSY (CLASS A)	Unit Price Excl Tax 4,75 €(3,98 £)
# 16	17100-LLJ1-900	PIPE ASSY INLET	Unit Price Excl Tax 19,08 €(15,98 £)
# 17	17111-LBD3-900	GASKET INLET PIPE A	Unit Price Excl Tax 2,42 €(2,03 £)
# 18	17112-LBD3-900	GASKET INLET PIPE B	Unit Price Excl Tax 2,75 €(2,30 £)
# 19	90521-GFY6-C00	WASHER-DRAIN PLUG (10MM)	Unit Price Excl Tax 0,83 €(0,70 £)		Special offer 1,00 €(0,84 £)
# 20	91001-GLW0-90A	BEARING BALL (SC04A50)(20X52X12)- VILO DROIT	Unit Price Excl Tax 15,75 €(13,19 £)
# 21	96100-62030-00	BEARING BALL (6203)(17X40X12)	Unit Price Excl Tax 6,58 €(5,51 £)
# 22	96100-62010-00	BEARING BALL (6201)(12X32X10)	Unit Price Excl Tax 14,08 €(11,79 £)
# 23	91006-KNBN-901	BEARING BALL (SC05A97)(25X56X12) - VILO GAUCHE	Unit Price Excl Tax 15,75 €(13,19 £)
# 24	91201-KNBN-C00	OIL SEAL (15, 6X25, 5X7)	Unit Price Excl Tax 5,75 €(4,81 £)
# 25	91202-KNBN-C00	OIL SEAL (20X31X7)	Unit Price Excl Tax 5,75 €(4,81 £)
# 26	91204-KNBN-C00	OIL SEAL (17X30X6)	Unit Price Excl Tax 7,42 €(6,21 £)
# 27	91305-LEH6-E00	O-RING (19, 8X1, 9)	Unit Price Excl Tax 0,92 €(0,77 £)
# 29	94050-06080	NUT (M06)	Unit Price Excl Tax 1,42 €(1,19 £)
# 30	94301-10200	PIN DOWEL (10X20)	Unit Price Excl Tax 1,17 €(0,98 £)
# 31	95002-02650	CLIP (6, 5MM)	Unit Price Excl Tax 0,83 €(0,70 £)
# 32	95801-08012-08	VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)	Not available	0,00 €(0,00 £)
# 33	95701-08040-08	VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X40/22 OR)	Not available	0,00 €(0,00 £)
# 34	90131-LEB1-900	BOLT FLANGE (M08X35)(BLACK)	Unit Price Excl Tax 2,75 €(2,30 £)
# 35	96001-06022-06	BOLT FLANGE (M06X22)(BLACK)	Unit Price Excl Tax 1,42 €(1,19 £)
# 36	96001-06032-06	BOLT FLANGE (M06X32)(BLACK)	Unit Price Excl Tax 2,33 €(1,95 £)
# 37	96001-06045-06	BOLT FLANGE (M06X45)(BLACK)	Unit Price Excl Tax 2,33 €(1,95 £)
# 38	96001-06055-06	BOLT FLANGE (M06X55)(BLACK)	Unit Price Excl Tax 1,50 €(1,26 £)
# 39	96100-62030-00	BEARING BALL (6203)(17X40X12)	Unit Price Excl Tax 6,58 €(5,51 £)
