CLUTCH

ELECTRICAL EQUIPMENT FOR KYMCO MXU 50 2T EURO II

TAIL LIGHT

3051A

(3051A) 3051A-LBD3-900

COIL ASSY IGNITION

3195A

(3195A) 3195A-LBA7-E00

HAZARD CONTROL ASSY

3860A

(3860A) 3860A-LCA5-E01

CONTROL ASSY LIGHTING

30400

(30400) 30400-KFA6-900

UNIT ASSY CDI

30700

(30700) 30700-KNBN-901

CAP ASSY NOISE SUPPRESOR

31600

(31600) 31600-LBA7-900

REGULATOR REC COMP

32100

(32100) 32100-LDB1-700

HARNESS WIRE

32101

(32101) 32101-LLB1-800

SUB CORD

35010

(35010) 35010-LCA4-90A

SWITCH ASSY COMB

(35010) 35010-LCA4-9V0

SWITCH ASSY COMB (AHO)

35111

(35111) 35111-LCA5-325-M1

KEY COMP(FOR SERVICE)

35111A

(35111A) 35111-LCA5-326-M1

KEY COMP(FOR SERVICE)

38110

(38110) 38110-KHB4-E0A

HORN COMP (D405)

38300

(38300) 38300-KECE-900

RELAY ASSY WINKER

38500

(38500) 38500-KFA6-900

SET START MAG

39000

(39000) 39000-LLB1-900

CONTROL UNIT GEAR CHANGE

90112

(90112) 90112-KRDR-900

BOLT FLANGE (M05X22)

90656

(90656) 90656-KCBC-900

BAND HARNESS WIRE

90656A

(90656A) 90656-KUDU-900-N1R

BAND HARNESS WIRE (BLACK BRUT)

94050

(94050) 94050-06080

NUT (M06)

95701

(95701) 95701-08012-06

BOLT FLANGE (M08X12)(BLACK)

98200

(98200) 98200-12000

FUSE 20A

	Part number	Description	Qty
# 3051A	3051A-LBD3-900	COIL ASSY IGNITION	33,25 €(28,47 £)
# 3195A	3195A-LBA7-E00	HAZARD CONTROL ASSY	49,92 €(42,75 £)
# 3860A	3860A-LCA5-E01	CONTROL ASSY LIGHTING	60,75 €(52,02 £)
# 30400	30400-KFA6-900	UNIT ASSY CDI	78,25 €(67,00 £)
# 30700	30700-KNBN-901	CAP ASSY NOISE SUPPRESOR	5,75 €(4,92 £)
# 31600	31600-LBA7-900	REGULATOR REC COMP	91,58 €(78,42 £)
# 32100	32100-LDB1-700	HARNESS WIRE	133,25 €(114,10 £)
# 32101	32101-LLB1-800	SUB CORD	3,92 €(3,36 £)
# 35010	35010-LCA4-90A	SWITCH ASSY COMB	47,42 €(40,60 £)
# 35010	35010-LCA4-9V0	SWITCH ASSY COMB (AHO)	48,25 €(41,32 £)	Special offer 57,90 €(49,58 £)
# 35111	35111-LCA5-325-M1	KEY COMP(FOR SERVICE)	8,25 €(7,06 £)
# 35111A	35111-LCA5-326-M1	KEY COMP(FOR SERVICE)	8,25 €(7,06 £)
# 38110	38110-KHB4-E0A	HORN COMP (D405)	19,92 €(17,06 £)
# 38300	38300-KECE-900	RELAY ASSY WINKER	21,58 €(18,48 £)
# 38500	38500-KFA6-900	SET START MAG	21,58 €(18,48 £)	Special offer 25,90 €(22,18 £)
# 39000	39000-LLB1-900	CONTROL UNIT GEAR CHANGE	49,08 €(42,03 £)
# 90112	90112-KRDR-900	BOLT FLANGE (M05X22)	0,92 €(0,79 £)
# 90656	90656-KCBC-900	BAND HARNESS WIRE	1,50 €(1,28 £)
# 90656A	90656-KUDU-900-N1R	BAND HARNESS WIRE (BLACK BRUT)	1,25 €(1,07 £)
# 94050	94050-06080	NUT (M06)	1,42 €(1,22 £)
# 95701	95701-08012-06	BOLT FLANGE (M08X12)(BLACK)	1,50 €(1,28 £)
# 98200	98200-12000	FUSE 20A	1,42 €(1,22 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL EQUIPMENT of your Kymco MXU 50 2T EURO II of MXU. Let us know if you have any questions.
