HANDLEBARS / SWITCHES FOR KYMCO YUP 50 2T EURO II

SPEEDOMETER

(1) 17910-KKD6-E00

CABLE COMP THROT

(2) 3515A-KGBG-C10

BOITIER COMMUTATEUR DROIT

(3) 3520A-KGBG-E00

SWITCH ASSY LEFT HANDLE COMP

(4) 35340-KKJ9-010

SWITCH ASSY FRONT STOP

(5) 43450-KKD6-E00

CABLE COMP REAR BRAKE

(6) 43452-GKAK-900

CLAMP BRAKE CABLE

(7) 43472-KEB7-900

RESSORT DE RAPPEL FREIN ARRIERE

(8) 45517-GFY6-900

HOLDER BRACKET

(9) 53100-KKD6-E00

HANDLE COMP STRG

(10) 53105-KNBN-C00

END HANDLE

(11) 53125-GEN5-C00

COLLAR HANDLE SET

(12) 53140-KNBN-C00-N1R

GRIP COMP THROTTLE (BLACK BRUT)

(13) 53166-KNBN-C00-N1R

GRIP LEFT HANDLE (BLACK BRUT)

(14) 53172-KTCT-C00

BRACKET LEFT HANDLE

(15) 53178-KXCX-E90-M3A

LEVER LEFT STRG HANDEL (SILVER)

(16) 5317B-KFA6-C00

BRACKET ASSY HANDEL LEFT (SILVER)

(17) 53204-KFA6-900

COVER HEAD LIGHT

(18) 53205-KFA6-E00-N8P

COVER FRONT HANDLE (LIGHT SILVER METAL)

(19) 53206-KFA6-900-N1R

COVER REAR HANDLE (BLACK BRUT)

(20) 88110-KEB7-E00

MIRROR ASSY RIGHT BACK

(21) 88120-KEB7-E00

MIRROR ASSY LEFT BACK

(22) 90106-GEN5-901

BOLT FLANGE (M10X50)(GOLD)

(23) 90115-LBC6-900

BOLT HANDEL LEVER PIVOT

(24) 90302-KNBN-C00

BOLT FLANGE (M05X10)(BLACK)

(25) 90304-GHE8-004-SY

NUT FLANGE (M10X10)

(26) 90656-KCBC-900

BAND HARNESS WIRE

(27) 93500-KGBG-900

SCREW TAPPING (M05X25)

(28) 93891-05030-06

SCREW PAN (M05X30)(BLACK)

(29) 93903-34360

SCREW TAPPING (M04X12)(BLACK)

(30) 93903-35360

SCREW TAPPING (M05X16)

(31) 94001-05080-0S

NUT HEX (M05)

(32) 95015-32001

JOINT B BRAKE ARM

(33) 95015-42000

NUT B ADJUST

(34) 95701-06025-08

BOLT FLANGE (M06X25)(GOLD)

(35) 96001-06012-06

BOLT FLANGE (M06X12)(BLACK)

	Part number	Description	Qty
# 1	17910-KKD6-E00	CABLE COMP THROT	20,75 €(17,78 £)
# 2	3515A-KGBG-C10	BOITIER COMMUTATEUR DROIT	Not available	0,00 €(0,00 £)
# 3	3520A-KGBG-E00	SWITCH ASSY LEFT HANDLE COMP	35,75 €(30,63 £)
# 4	35340-KKJ9-010	SWITCH ASSY FRONT STOP	6,58 €(5,64 £)
# 5	43450-KKD6-E00	CABLE COMP REAR BRAKE	19,08 €(16,35 £)
# 6	43452-GKAK-900	CLAMP BRAKE CABLE	1,25 €(1,07 £)
# 7	43472-KEB7-900	RESSORT DE RAPPEL FREIN ARRIERE	Not available	0,00 €(0,00 £)
# 8	45517-GFY6-900	HOLDER BRACKET	5,17 €(4,43 £)
# 9	53100-KKD6-E00	HANDLE COMP STRG	39,92 €(34,20 £)
# 10	53105-KNBN-C00	END HANDLE	1,75 €(1,50 £)
# 11	53125-GEN5-C00	COLLAR HANDLE SET	3,58 €(3,07 £)
# 12	53140-KNBN-C00-N1R	GRIP COMP THROTTLE (BLACK BRUT)	8,75 €(7,50 £)
# 13	53166-KNBN-C00-N1R	GRIP LEFT HANDLE (BLACK BRUT)	4,75 €(4,07 £)
# 14	53172-KTCT-C00	BRACKET LEFT HANDLE	9,58 €(8,21 £)
# 15	53178-KXCX-E90-M3A	LEVER LEFT STRG HANDEL (SILVER)	10,75 €(9,21 £)
# 16	5317B-KFA6-C00	BRACKET ASSY HANDEL LEFT (SILVER)	38,25 €(32,77 £)
# 17	53204-KFA6-900	COVER HEAD LIGHT	19,08 €(16,35 £)
# 18	53205-KFA6-E00-N8P	COVER FRONT HANDLE (LIGHT SILVER METAL)	30,75 €(26,35 £)
# 19	53206-KFA6-900-N1R	COVER REAR HANDLE (BLACK BRUT)	12,42 €(10,64 £)
# 20	88110-KEB7-E00	MIRROR ASSY RIGHT BACK	9,92 €(8,50 £)
# 21	88120-KEB7-E00	MIRROR ASSY LEFT BACK	9,92 €(8,50 £)
# 22	90106-GEN5-901	BOLT FLANGE (M10X50)(GOLD)	1,50 €(1,29 £)
# 23	90115-LBC6-900	BOLT HANDEL LEVER PIVOT	1,42 €(1,22 £)
# 24	90302-KNBN-C00	BOLT FLANGE (M05X10)(BLACK)	1,50 €(1,29 £)
# 25	90304-GHE8-004-SY	NUT FLANGE (M10X10)	2,33 €(2,00 £)
# 26	90656-KCBC-900	BAND HARNESS WIRE	1,50 €(1,29 £)
# 27	93500-KGBG-900	SCREW TAPPING (M05X25)	1,00 €(0,86 £)
# 28	93891-05030-06	SCREW PAN (M05X30)(BLACK)	0,83 €(0,71 £)
# 29	93903-34360	SCREW TAPPING (M04X12)(BLACK)	1,25 €(1,07 £)		Special offer 1,50 €(1,29 £)
# 30	93903-35360	SCREW TAPPING (M05X16)	1,25 €(1,07 £)
# 31	94001-05080-0S	NUT HEX (M05)	0,83 €(0,71 £)
# 32	95015-32001	JOINT B BRAKE ARM	1,83 €(1,57 £)
# 33	95015-42000	NUT B ADJUST	2,42 €(2,07 £)
# 34	95701-06025-08	BOLT FLANGE (M06X25)(GOLD)	1,33 €(1,14 £)
# 35	96001-06012-06	BOLT FLANGE (M06X12)(BLACK)	1,17 €(1,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the HANDLEBARS / SWITCHES of your Kymco YUP 50 2T EURO II of YUP. Let us know if you have any questions.
