ENGINE CASINGS

FRAME / CARRIER FOR KYMCO MXU 700I IRS 4T T3B

INDICATORS

19505-KED9

(19505-KED9) 19505-KED9-900

CLAMP WATER HOSE

19505-LBA2

(19505-LBA2) 19505-LBA2-E00

CLAMP WATER HOSE

50100

(50100) 50100-AGB6-E00

BODY COMP FRAME

50204

(50204) 50204-LKM5-900

HEAT PROTECTOR STAY

50218

(50218) 50218-LKM5-E00

STAY ELECTRIC SET

50227

(50227) 50227-LKA8-E00

STAY ECU

50330

(50330) 50330-LEA7-E00

SPONGE BATTERY COVER

50614

(50614) 50614-ALC1-E00

STAY RIGHT FLOOR PANEL

50615

(50615) 50615-ALC1-E00

STAY LEFT FLOOR PANEL

77330

(77330) 77330-AGA8-E00

CARRIER REAR

77335

(77335) 77335-AGA8-E00

STAY REAR CARRIER

77342

(77342) 77342-AGB3-E00

STAY BRAKE SENSOR

77430

(77430) 77430-AGA8-E00

CARRIER FRONT

81202

(81202) 81202-LDB5-E00

STAY NUMBER PLATE

85100

(85100) 85100-AGA8-E00

PIPE COMP FRONT BUMPER

85200

(85200) 85200-AGA8-E00

SUPPORT PIPE COMP BACK

90301

(90301) 90301-6C93-001

NUT CAP (M06)

90304

(90304) 90304-GLW0-90A

NUT FLANGE (M10X10)

94050-06060

(94050-06060) 94050-06060

NUT (M06)

94050-08060

(94050-08060) 94050-08060

NUT (M08)

95701-06016

(95701-06016) 95701-06016-06

BOLT FLANGE (M06X16)(BLACK)

95701-08016

(95701-08016) 95701-08016-06

BOLT FLANGE (M08X16)(BLACK)

95701-08025

(95701-08025) 95701-08025-06

BOLT FLANGE (M08X25)(BLACK)

95701-KKA8

(95701-KKA8) 95701-KKA8-900

BOLT TORQUE (M06X10)

95801-10090

(95801-10090) 95801-10090-06

BOLT FLANGE (M10X90)(BLACK)

95801-10110

(95801-10110) 95801-10110-06

BOLT FLANGE (M10X110)(BLACK)

95801-10120

(95801-10120) 95801-10120-06

BOLT FLANGE (M10X120)(BLACK)

95801-10195

(95801-10195) 95801-10195-06

BOLT FLANGE (M10X195)(BLACK)

	Part number	Description	Qty
# 19505-KED9	19505-KED9-900	CLAMP WATER HOSE	2,50 €(2,14 £)
# 19505-LBA2	19505-LBA2-E00	CLAMP WATER HOSE	3,58 €(3,07 £)
# 50100	50100-AGB6-E00	BODY COMP FRAME	533,33 €(456,64 £)
# 50204	50204-LKM5-900	HEAT PROTECTOR STAY	10,42 €(8,92 £)
# 50218	50218-LKM5-E00	STAY ELECTRIC SET	16,58 €(14,20 £)
# 50227	50227-LKA8-E00	STAY ECU	6,58 €(5,63 £)
# 50330	50330-LEA7-E00	SPONGE BATTERY COVER	0,58 €(0,50 £)
# 50614	50614-ALC1-E00	STAY RIGHT FLOOR PANEL	45,75 €(39,17 £)
# 50615	50615-ALC1-E00	STAY LEFT FLOOR PANEL	45,75 €(39,17 £)
# 77330	77330-AGA8-E00	CARRIER REAR	154,08 €(131,92 £)
# 77335	77335-AGA8-E00	STAY REAR CARRIER	24,08 €(20,62 £)
# 77342	77342-AGB3-E00	STAY BRAKE SENSOR	5,42 €(4,64 £)
# 77430	77430-AGA8-E00	CARRIER FRONT	124,92 €(106,96 £)
# 81202	81202-LDB5-E00	STAY NUMBER PLATE	9,58 €(8,20 £)
# 85100	85100-AGA8-E00	PIPE COMP FRONT BUMPER	124,92 €(106,96 £)
# 85200	85200-AGA8-E00	SUPPORT PIPE COMP BACK	79,08 €(67,71 £)
# 90301	90301-6C93-001	NUT CAP (M06)	0,83 €(0,71 £)
# 90304	90304-GLW0-90A	NUT FLANGE (M10X10)	1,50 €(1,28 £)
# 94050-06060	94050-06060	NUT (M06)	1,42 €(1,22 £)
# 94050-08060	94050-08060	NUT (M08)	1,42 €(1,22 £)
# 95701-06016	95701-06016-06	BOLT FLANGE (M06X16)(BLACK)	0,83 €(0,71 £)
# 95701-08016	95701-08016-06	BOLT FLANGE (M08X16)(BLACK)	0,92 €(0,79 £)
# 95701-08025	95701-08025-06	BOLT FLANGE (M08X25)(BLACK)	1,50 €(1,28 £)
# 95701-KKA8	95701-KKA8-900	BOLT TORQUE (M06X10)	1,92 €(1,64 £)
# 95801-10090	95801-10090-06	BOLT FLANGE (M10X90)(BLACK)	3,33 €(2,85 £)
# 95801-10110	95801-10110-06	BOLT FLANGE (M10X110)(BLACK)	2,75 €(2,35 £)
# 95801-10120	95801-10120-06	BOLT FLANGE (M10X120)(BLACK)	2,50 €(2,14 £)
# 95801-10195	95801-10195-06	BOLT FLANGE (M10X195)(BLACK)	4,08 €(3,49 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME / CARRIER of your Kymco MXU 700I IRS 4T T3B of MXU. Let us know if you have any questions.
