RIGHT CASING

CRANKCASE FOR KYMCO MAXXER 90 4T TOUT TERRAIN

FRAME

(1) 11100-LBD4-900

CRANK CASE RIGHT

(2) 11102-LBD3-900

RUBBER BUSH ENGINE HANGER

(3) 11192-LBD4-900

GASKET CRANK CASE

(4) 11200-LBD4-305

CRANK CASE LEFT

(5) 11203-LBD3-900

UNDER RUBBER BUSH REAR CUSHIO

(6) 11205-GHAH-C00

BUSH (8X12X8)

(7) 11341-KHC4-900-N8A

COVER LEFT SIDE (LIGHT SILVER METAL)

(8) 11342-LAB4-900

PLATE LEFT COVER

(9) 11395-LBD4-900

GASKET LEFT COVER

(10) 28223-KNBN-W10

GUIDE DE PRISE DE KICK

(11) 28230-KNBN-901

GEAR COMP KICK DRIVEN

(12) 28250-KNBN-901

SPINDLE COMP KICK STARTER

(13) 28253-GBN2-C00

BUSH KICK SPINDLE

(14) 28255-GFS6-C00

WASHER (5,11X33,48X36,98)

(15) 28281-GBN2-60A

SPRING KICK RETURN

(16) 90031-KHC4-900

BOLT STUD (M08X182,5)

(17) 90032-KHC4-900

BOLT STUD (M08X190,5)

(18) 90412-3K29-C00

WASHER THRUST (1,00X10,00X18,00)

(19) 90451-GBN2-C00

WASHER PLAIN (2,06X14,20X20,96)

(20) KY-99-1000

REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)

(21) 9052A-PUA3-B50

BOLT ASSY DRAIN PLUG (M12X15)

21*

(21*) 95801-08012-08

VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)

(22) 91106-KHC4-90A

BEARING NEEDLE (15MM)

(23) 91202-GFY6-C00

JOINT SPI 19,8 X 30 X 5

(24) 91202-KKJ9-C00

OIL SEAL (20X32X6)

(25) 94301-08140

PIN DOWEL (8X14)

(26) 94511-14000

CIRCLIP EX (14MM)

(27) 95801-08012-08

VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)

(28) 95701-08045-08

VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X45/25 OR)

(29) 95701-08060-08

BOLT FLANGE (M08X60)(GOLD)

(30) 96001-06028-060

BOLT FLANGE (M06X28)(BLACK)

(31) 96001-06035-06

BOLT FLANGE (M06X35)(BLACK)

(32) 96001-06045-06

BOLT FLANGE (M06X45)(BLACK)

(33) 96001-GFY6-900

BOLT FLANGE (M05X10)(GOLD)

(34) 96100-62030-00

BEARING BALL (6203)(17X40X12)

(35) 96100-62040-00

BEARING BALL (6204)(20X47X14)

	Part number	Description	Qty
# 1	11100-LBD4-900	CRANK CASE RIGHT	87,42 €(74,66 £)
# 2	11102-LBD3-900	RUBBER BUSH ENGINE HANGER	3,75 €(3,20 £)
# 3	11192-LBD4-900	GASKET CRANK CASE	5,75 €(4,91 £)
# 4	11200-LBD4-305	CRANK CASE LEFT	137,42 €(117,36 £)
# 5	11203-LBD3-900	UNDER RUBBER BUSH REAR CUSHIO	2,92 €(2,49 £)
# 6	11205-GHAH-C00	BUSH (8X12X8)	1,50 €(1,28 £)
# 7	11341-KHC4-900-N8A	COVER LEFT SIDE (LIGHT SILVER METAL)	87,42 €(74,66 £)
# 8	11342-LAB4-900	PLATE LEFT COVER	2,67 €(2,28 £)
# 9	11395-LBD4-900	GASKET LEFT COVER	15,75 €(13,45 £)
# 10	28223-KNBN-W10	GUIDE DE PRISE DE KICK	Not available	0,00 €(0,00 £)
# 11	28230-KNBN-901	GEAR COMP KICK DRIVEN	21,58 €(18,43 £)
# 12	28250-KNBN-901	SPINDLE COMP KICK STARTER	23,25 €(19,86 £)
# 13	28253-GBN2-C00	BUSH KICK SPINDLE	1,50 €(1,28 £)
# 14	28255-GFS6-C00	WASHER (5, 11X33, 48X36, 98)	1,25 €(1,07 £)
# 15	28281-GBN2-60A	SPRING KICK RETURN	4,75 €(4,06 £)
# 16	90031-KHC4-900	BOLT STUD (M08X182, 5)	4,75 €(4,06 £)
# 17	90032-KHC4-900	BOLT STUD (M08X190, 5)	4,75 €(4,06 £)
# 18	90412-3K29-C00	WASHER THRUST (1, 00X10, 00X18, 00)	1,00 €(0,85 £)
# 19	90451-GBN2-C00	WASHER PLAIN (2, 06X14, 20X20, 96)	1,25 €(1,07 £)
# 20	KY-99-1000	REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)	Not available	0,00 €(0,00 £)
# 21	9052A-PUA3-B50	BOLT ASSY DRAIN PLUG (M12X15)	2,50 €(2,14 £)
# 21*	95801-08012-08	VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)	Not available	0,00 €(0,00 £)
# 22	91106-KHC4-90A	BEARING NEEDLE (15MM)	5,42 €(4,63 £)
# 23	91202-GFY6-C00	JOINT SPI 19, 8 X 30 X 5	Not available	0,00 €(0,00 £)
# 24	91202-KKJ9-C00	OIL SEAL (20X32X6)	5,42 €(4,63 £)
# 25	94301-08140	PIN DOWEL (8X14)	1,42 €(1,21 £)
# 26	94511-14000	CIRCLIP EX (14MM)	1,42 €(1,21 £)
# 27	95801-08012-08	VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X12 OR)	Not available	0,00 €(0,00 £)
# 28	95701-08045-08	VIS EPAULEE A TETE HEXAGONALE DE 12 (M08X45/25 OR)	Not available	0,00 €(0,00 £)
# 29	95701-08060-08	BOLT FLANGE (M08X60)(GOLD)	1,42 €(1,21 £)
# 30	96001-06028-060	BOLT FLANGE (M06X28)(BLACK)	4,33 €(3,70 £)
# 31	96001-06035-06	BOLT FLANGE (M06X35)(BLACK)	0,83 €(0,71 £)
# 32	96001-06045-06	BOLT FLANGE (M06X45)(BLACK)	2,33 €(1,99 £)
# 33	96001-GFY6-900	BOLT FLANGE (M05X10)(GOLD)	0,92 €(0,79 £)
# 34	96100-62030-00	BEARING BALL (6203)(17X40X12)	6,58 €(5,62 £)
# 35	96100-62040-00	BEARING BALL (6204)(20X47X14)	15,75 €(13,45 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
