6. CYLINDER HEAD/VALVES DINK 50/ 125
CYLINDER HEAD Nuts
REMOVE
Remove the camshaft. (Refer to the
"camshaft remove" section in the chapter 6)
Remove the carburetor. (Refer to the
"CARBURETOR REMOVE" section in the
chapter 12)
Remove the exhaust muffler. (Refer to the
"EXHAUST MUFFLER REMOVE" section
in the chapter 13)
Remove the two nuts and then remove the
carburetor intake manifold and insulator.
Intake Manifold
Remove the cooling fan cover. ( 8-3)
Remove the engine cover bolts and screws.
Separate the engine cover joint claws.
Remove seal shroud, then remove two bolts Seal Shroud
and cylinder head.
Bolts
6-25
