1. GENERAL INFORMATION ATV 50
Torque
Item Q`ty Thread dia.(mm) kgf-m (N-m, Remarks
lbf-ft)
Front shock absorber lower mount bolt 2 10 4 (40, 29)
Rear fork axle 1 14 7 (70, 50)
Rear hub nut 4 12 7 (70, 50)
Rear wheel shaft nut 2 32 12 (120, 86)
Rear engine bracket up bolt 1 10 4 (40, 29)
Rear engine bracket bolt 2 10 4 (40, 29)
Engine hanger bracket bolt 1 10 4.5 (45, 32)
SPECIAL TOOLS
Tool Name Tool No. Memo
Flywheel puller A120E00001
Oil seal and bearing install A120E00014
Crankshaft install A120E00016
Universal holder A120E00017
Crankshaft & crankcase install A120E00024
Crankcase puller A120E00026
Crankshaft Bearing puller A120E00030
Clutch spring compressor A120E00034
Bearing puller A120E00037
Nut wrench A120F00010
LUBRICATION POINTS
ENGINE
Lubrication Points Lubricant
Crankcase sliding & movable parts JASO-FC or API-TC
Cylinder movable parts JASO-FC or API-TC
Transmission gear (final gear) Gear oil: SAE90#
Kick starter spindle bushing Grease
Drive pulley movable parts Grease
Starter pinion movable parts Grease
1-14
