6. CYLINDER HEAD/VALVES PEOPLE 250
Remove the camshaft holder. Camshaft Holder
Cam Chain Dowel Pins
Remove the dowel pins.
Remove the camshaft gear from the cam
chain to remove the camshaft.
Camshaft Gear
CAMSHAFT INSPECTION
Check each cam lobe for wear or damage.
Measure the cam lobe height.
Service Limits:
IN: 34.14mm replace if below
EX:34.02mm replace if below
Camshaft Bearings
Check each camshaft bearing for play or
damage. Replace the camshaft assembly with
a new one if the bearings are noisy or have
excessive play.
6-5
