12. COOLING SYSTEM People GT 300i SERVICE INFORMATION GENERAL INSTRUCTIONS · The water pump must be serviced after removing the engine. Other cooling system service can be done with the engine installed in the frame. · The engine must be cool before servicing the cooling system. When the coolant temperature is over 100, never remove the radiator cap to release the pressure because the boiling coolant may cause danger. · Avoid spilling coolant on painted surfaces because the coolant will corrode the painted surfaces. Wash off any spilled coolant with fresh water as soon as possible. · After servicing the system, check for leaks with a cooling system tester. TORQUE VALUES Water pump impeller 1.0~1.4 kgf-m (11.8 N-m) Water pump cover bolt 1.0~1.4 kgf-m (11.8 N-m) TROUBLESHOOTING Engine temperature too high Coolant leaks · Faulty temperature gauge or thermosensor · Faulty pump mechanical (water) seal · Faulty radiator cap · Deteriorated O-rings · Faulty thermostat · Damaged or deteriorated water hoses · Insufficient coolant · Passages blocked in hoses or water jacket · Clogged radiator fins · Passages blocked in radiator · Faulty water pump Temperature gauge shows the wrong temperature · Faulty temperature gauge or thermosensor · Faulty thermostat SPECIFICATIONS Radiator cap relief pressure 0.90.15 kg/cm Begins to open 71 Thermostat temperature Full-open 80 Valve lift 3.54.5 mm Radiator: 820 cc Coolant capacity Total 1120 cc Reserve tank: 300 cc 12-2
