13. STEERINGHANDLEBAR/FRONTWHEEL/FRONT
BRAKE/FRONTSHOCKABSORBER/FRONTFORK SUPER 9 50
Circlip Dust Boot
Install the oil seal
Install the circlip.
Install the dusts seal and dust boot.
Dust Seal
INSTALLATION
Install the front shock absorbers onto the
front fork.
Install and tighten the front shock absorber
upper mount bolts.
Tighten the lower mount bolts.
Align the upper mount bolt hole with the
groove on the front fork.
Install the front wheel. ( 13-7)
13-17
