3. INSPECTION/ADJUSTMENT DOWNTOWN 125i
CLUTCH SHOE WEAR
Start the engine and check the clutch
operation by increasing the engine speed
gradually.
If the scooter tends to creep, or the engine
stalls, check the clutch shoes for wear and
replace if necessary (refer to the "DRIVE
PULLEY, DRIVE BELT AND DRIVEN
PULLEY" section in the chapter 8).
Horizontally Adjusting Screw
HEADLIGHT AIM
Remove the front cover
Place the scooter on a level surface
Adjust the headlight beam adjuster.
A clockwise rotation moves the beam up
and counterclockwise rotation moves the
beam down.
Adjust the headlight beam horizontally by
turning the horizontal beam adjuster.
A clockwise rotation moves the beam toward
the right side of the rider.
Vertically Adjusting Screw
3-17
