12. COOLING SYSTEM GRAND DINK 125/150
Bolts Radiator
RADIATOR INSTALLATION
Install the radiator on the radiator bracket
with the two bolts and one nut.
Nut
.
Upper Hose
Connect the upper and lower hoses and
secure them with hose bands.
Connect the thermostatic switch wire and
fan motor wire couplers.
Thermostatic Switch Wire Lower Hose
Overflow Tube
Connect the overflow tube and secure with
the tube clamp.
Connect the vent tube to the radiator filler.
Fill the radiator with coolant. ( 3-9)
After installation, check for coolant leaks.
Air Vent Tube
12-8
