13. DRIVE TRAIN UXU 500
Inspect the front assy cvj spline for wear or
damage.
If any damages are found, replace them with
a new one.
Inspect the front assy cvj for bends.
If any damages are found, replace them with
a new one.
Do not attempt to straighten a bent shaft;
this may dangerously weaken the shaft.
ASSEMBLY
Circlip Case Side Joint
Snap Ring Cage
Boot Band Band
Boot Band
Circlip Band
Front Drive Shaft
Wash all parts (except for the boots) before assembly,
clean the inside and outside of the boot with a cloth.
Do not wash the boots in any commercially available
degreaser, such as gasoline or kerosene. Washing in a
degreaser causes deterioration of the boot.
13-7
