ENGINE CASINGS

FRAME FOR KYMCO VISAR 125I E4

INDICATORS

5060A

(5060A) 5060A-LKH3-C00

BAR RIGHT STEP ASSY

5060B

(5060B) 5060B-LKH3-C00

BAR LEFT STEP ASSY

50100

(50100) 50100-LKH3-E03

BODY COMP FRAME VISAR 125

50131

(50131) 50131-LKH3-C00

STAY HORN

50136

(50136) 50136-LKH3-E03

STAY ANGLE DETECT SENSOR

50141

(50141) 50141-ABD6-C00

STAY ECU

50195

(50195) 50195-LKH3-E03

CBS STAY

50315

(50315) 50315-ABD6-C00

STAY START MAG,

50351

(50351) 50351-LKH3-C00

ENGINE HANGER ASSY

50353

(50353) 50353-ALH8-C10

PLATE RIGHT ENGINE UP HANGER

50354-ALH8

(50354-ALH8) 50354-ALH8-C10

PLATE LEFT ENGINE UP HANGE

50354-LKH3

(50354-LKH3) 50354-LKH3-C00

BAR TANK SIDE COVER RIGHT

50355

(50355) 50355-LKH3-C00

BAR TANK SIDE COVER LEFT

50356

(50356) 50356-LKH3-C00

BAR UNDER COWL

50505

(50505) 50505-LDC8-E10

STOPPER RUBBER MAIN STAND

50611

(50611) 50611-LKH3-C00-M5A

BRACKET RIGHT PILLION STEP

50621

(50621) 50621-LKH3-C00-M5A

BRACKET LEFT PILLION STEP

92000

(92000) 92000-06020-0HG

BOLT HEX (M06X20)

93903

(93903) 93903-35380-G

SCREW TAPPING (M05X16)

94002

(94002) 94002-06080-0SG

NUT HEX (M06)

94050-06080

(94050-06080) 94050-06080-G

NUT (M06)

94050-08080

(94050-08080) 94050-08080-G

NUT (M08)

94050-10080

(94050-10080) 94050-10080-G

NUT (M10)

94102-10800

(94102-10800) 94102-10800

WASHER PLAIN (1,68X10,17X21,92)

94102-LKH3

(94102-LKH3) 94102-LKH3-C00

WASHER PLAIN (14MM)

95701-06012

(95701-06012) 95701-06012-08

BOLT FLANGE (M06X12)(GOLD)

95701-06012-08G

(95701-06012-08G) 95701-06012-08G

BOLT FLANGE (M06X12)(GOLD)

95701-08016

(95701-08016) 95701-08016-08G

BOLT FLANGE (M08X16)(GOLD)

95701-08070

(95701-08070) 95701-08070-08G

BOLT FLANGE (M08X70)(GOLD)

95701-08085

(95701-08085) 95701-08085-08G

BOLT FLANGE (M08X85)(GOLD)

95801-08090

(95801-08090) 95801-08090-08G

BOLT FLANGE (M08X90)(GOLD)

95801-10040

(95801-10040) 95801-10040-08G

BOLT FLANGE (M10X40)(GOLD)

95801-10110

(95801-10110) 95801-10110-08G

BOLT FLANGE (M10X110)(GOLD)

	Part number	Description	Qty
# 5060A	5060A-LKH3-C00	BAR RIGHT STEP ASSY	19,08 €(16,34 £)
# 5060B	5060B-LKH3-C00	BAR LEFT STEP ASSY	19,08 €(16,34 £)
# 50100	50100-LKH3-E03	BODY COMP FRAME VISAR 125	208,25 €(178,30 £)
# 50131	50131-LKH3-C00	STAY HORN	3,58 €(3,07 £)
# 50136	50136-LKH3-E03	STAY ANGLE DETECT SENSOR	4,33 €(3,71 £)
# 50141	50141-ABD6-C00	STAY ECU	7,92 €(6,78 £)
# 50195	50195-LKH3-E03	CBS STAY	1,25 €(1,07 £)
# 50315	50315-ABD6-C00	STAY START MAG,	2,33 €(1,99 £)
# 50351	50351-LKH3-C00	ENGINE HANGER ASSY	47,42 €(40,60 £)
# 50353	50353-ALH8-C10	PLATE RIGHT ENGINE UP HANGER	3,58 €(3,07 £)
# 50354-ALH8	50354-ALH8-C10	PLATE LEFT ENGINE UP HANGE	2,50 €(2,14 £)
# 50354-LKH3	50354-LKH3-C00	BAR TANK SIDE COVER RIGHT	10,42 €(8,92 £)
# 50355	50355-LKH3-C00	BAR TANK SIDE COVER LEFT	10,42 €(8,92 £)
# 50356	50356-LKH3-C00	BAR UNDER COWL	34,92 €(29,90 £)
# 50505	50505-LDC8-E10	STOPPER RUBBER MAIN STAND	2,50 €(2,14 £)
# 50611	50611-LKH3-C00-M5A	BRACKET RIGHT PILLION STEP	47,42 €(40,60 £)
# 50621	50621-LKH3-C00-M5A	BRACKET LEFT PILLION STEP	47,42 €(40,60 £)
# 92000	92000-06020-0HG	BOLT HEX (M06X20)	0,92 €(0,79 £)
# 93903	93903-35380-G	SCREW TAPPING (M05X16)	1,00 €(0,86 £)
# 94002	94002-06080-0SG	NUT HEX (M06)	1,42 €(1,22 £)
# 94050-06080	94050-06080-G	NUT (M06)	1,42 €(1,22 £)
# 94050-08080	94050-08080-G	NUT (M08)	1,42 €(1,22 £)
# 94050-10080	94050-10080-G	NUT (M10)	1,42 €(1,22 £)
# 94102-10800	94102-10800	WASHER PLAIN (1, 68X10, 17X21, 92)	1,00 €(0,86 £)
# 94102-LKH3	94102-LKH3-C00	WASHER PLAIN (14MM)	1,00 €(0,86 £)
# 95701-06012	95701-06012-08	BOLT FLANGE (M06X12)(GOLD)	1,42 €(1,22 £)
# 95701-06012-08G	95701-06012-08G	BOLT FLANGE (M06X12)(GOLD)	1,42 €(1,22 £)
# 95701-08016	95701-08016-08G	BOLT FLANGE (M08X16)(GOLD)	0,92 €(0,79 £)
# 95701-08070	95701-08070-08G	BOLT FLANGE (M08X70)(GOLD)	1,92 €(1,64 £)
# 95701-08085	95701-08085-08G	BOLT FLANGE (M08X85)(GOLD)	1,92 €(1,64 £)
# 95801-08090	95801-08090-08G	BOLT FLANGE (M08X90)(GOLD)	2,08 €(1,78 £)
# 95801-10040	95801-10040-08G	BOLT FLANGE (M10X40)(GOLD)	3,25 €(2,78 £)
# 95801-10110	95801-10110-08G	BOLT FLANGE (M10X110)(GOLD)	2,75 €(2,35 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Kymco, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
