REAR FAIRINGS

RIGHT CASING FOR KYMCO VISAR 125I E4

ENGINE CASINGS

11330

(11330) 11330-LKH3-C00-45A

COVER COMP RIGHT CRANK CASE (BLACK)

11393

(11393) 11393-LKH3-C00

GASKET RIGHT CRANK CASE COVER

15650

(15650) 15650-PWA1-C00

CAP COMP OIL FILLER

15661

(15661) 15661-LBA7-C00

FINDER OIL LEVEL

22810

(22810) 22810-LKH3-C00

LEVER COMP CLUTCH

22815

(22815) 22815-LBG5-C10

SPRING CLUTCH LEVER

22838

(22838) 22838-LKH3-C00

HOLDER CLUTCH WIRE

22847

(22847) 22847-KED9-C00

ROD CLUTCH LIFTER

90409

(90409) 90409-LEC8-C00

WASHER FINDER OIL LEVEL

91201

(91201) 91201-LEF2-C10

OIL SEAL (12X22X5)

91307

(91307) 91307-0E35-W10

O-RING (18X3)

94301

(94301) 94301-08140

PIN DOWEL (8X14)

94305

(94305) 94305-LBG5-C10

PIN (3X10)

96001-06010

(96001-06010) 96001-06010-08

VIS EPAULEE A TETE HEXAGONALE DE 08 (M06X10 OR)

96001-06040

(96001-06040) 96001-06040-07

BOLT FLANGE (M06X40)(BLACK)

96001-06045

(96001-06045) 96001-06045-07

BOLT FLANGE (M06X45)(BLACK)

	Part number	Description	Qty
# 11330	11330-LKH3-C00-45A	COVER COMP RIGHT CRANK CASE (BLACK)	116,58 €(99,88 £)
# 11393	11393-LKH3-C00	GASKET RIGHT CRANK CASE COVER	8,75 €(7,50 £)
# 15650	15650-PWA1-C00	CAP COMP OIL FILLER	2,33 €(2,00 £)
# 15661	15661-LBA7-C00	FINDER OIL LEVEL	6,00 €(5,14 £)
# 22810	22810-LKH3-C00	LEVER COMP CLUTCH	8,75 €(7,50 £)
# 22815	22815-LBG5-C10	SPRING CLUTCH LEVER	1,25 €(1,07 £)
# 22838	22838-LKH3-C00	HOLDER CLUTCH WIRE	2,50 €(2,14 £)
# 22847	22847-KED9-C00	ROD CLUTCH LIFTER	3,58 €(3,07 £)
# 90409	90409-LEC8-C00	WASHER FINDER OIL LEVEL	1,00 €(0,86 £)
# 91201	91201-LEF2-C10	OIL SEAL (12X22X5)	2,42 €(2,07 £)
# 91307	91307-0E35-W10	O-RING (18X3)	1,25 €(1,07 £)
# 94301	94301-08140	PIN DOWEL (8X14)	1,42 €(1,22 £)
# 94305	94305-LBG5-C10	PIN (3X10)	2,00 €(1,71 £)
# 96001-06040	96001-06040-07	BOLT FLANGE (M06X40)(BLACK)	1,92 €(1,64 £)
# 96001-06045	96001-06045-07	BOLT FLANGE (M06X45)(BLACK)	2,33 €(2,00 £)
# 96001-06010	96001-06010-08	VIS EPAULEE A TETE HEXAGONALE DE 08 (M06X10 OR)	Not available	0,00 €(0,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Kymco, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
