EXHAUST

CLUTCH / VARIATOR FOR KYMCO XCITING 400I 4T EURO III

ELECTRICAL EQUIPMENT

(1) 11347-LKF5-E00

BOSS DRIVE FACE

(2) 11357-LKF5-E00

BOSS DRIVE SHAFT

(3) 22100-LKF5-E00

CLUTCH OUTER

(4) 22102-LKF5-E00

FACE COMP DRIVE

(5) 22105-LKF5-E00

BOSS DRIVE FACE

(6) 22110-LKF5-E00

FACE COMP MOVABLE DRIVE

(7) 22121-LKF5-305

ROLLER SET WEIGHT 25X20 17,0 GR

(8) 22130-LKF5-E00

PLATE RAMP

(9) 22300-LKF5-E00

PLATE ASSY DRIVE

(10) 22350-LKF5-E00

PLATE COMP DRIVEN

(11) 22361-LKF5-E00

PLATE CLUTCH SIDE

(12) 22401-LKF5-E00

SPRING CLUTCH SHOES

(13) 22535-LKF5-305

WEIGHT CLUTCH

(14) 22804-GBB2-001

RUBBER CLUTCH DUMPER

(15) 2301A-LKF5-E00

PULLEY SUB ASSY DRIVEN

(16) 23100-LKF5-E01

BELT DRIVE (E100)/(N-6M)

(17) 23200-LKF5-E00

FACE ASSY DRIVEN

(18) 23220-LKF5-E00

FACE COMP MOVABLE DRIVEN

(19) 23225-LKF5-E00

PIN ROLLER GUIDE

(20) 23233-LKF5-E00

SPRING DRIVEN FACE

(21) 23237-LKF5-E00

COLLAR SPRING

(22) 23238-LKF5-E01

COLLAR SPRING

(23) 90201-LKF5-E00

NUT HEX

(24) 90202-LDB5-E00

NUT SPECIAL (M36)

(25) 90605-1F66-C00

CIRCLIP (7MM)

(26) 91002-LKF5-E00

BEARING BALL

(27) 91004-LBA2-E00

BEARING NEEDLE (25X33X18)

(28) 91211-LDB5-E00

SEAL DRIVEN FACE (40,2X47X4)

(29) 91351-LDB5-E00

O-RING (48X46X2,0)

(30) 94050-LKF5-E00

NUT (M18)

(31) 94520-30000

CIRCLIP IN (22MM)

	Part number	Description	Qty
# 1	11347-LKF5-E00	BOSS DRIVE FACE	19,92 €(17,14 £)
# 2	11357-LKF5-E00	BOSS DRIVE SHAFT	19,92 €(17,14 £)
# 3	22100-LKF5-E00	CLUTCH OUTER	44,92 €(38,65 £)
# 4	22102-LKF5-E00	FACE COMP DRIVE	39,92 €(34,35 £)
# 5	22105-LKF5-E00	BOSS DRIVE FACE	28,25 €(24,31 £)
# 6	22110-LKF5-E00	FACE COMP MOVABLE DRIVE	76,58 €(65,90 £)
# 7	22121-LKF5-305	ROLLER SET WEIGHT 25X20 17, 0 GR	18,25 €(15,70 £)
# 8	22130-LKF5-E00	PLATE RAMP	28,25 €(24,31 £)
# 9	22300-LKF5-E00	PLATE ASSY DRIVE	120,75 €(103,91 £)
# 10	22350-LKF5-E00	PLATE COMP DRIVEN	28,25 €(24,31 £)
# 11	22361-LKF5-E00	PLATE CLUTCH SIDE	8,75 €(7,53 £)
# 12	22401-LKF5-E00	SPRING CLUTCH SHOES	2,08 €(1,79 £)
# 13	22535-LKF5-305	WEIGHT CLUTCH	83,25 €(71,64 £)
# 14	22804-GBB2-001	RUBBER CLUTCH DUMPER	3,92 €(3,37 £)
# 15	2301A-LKF5-E00	PULLEY SUB ASSY DRIVEN	283,25 €(243,74 £)
# 16	23100-LKF5-E01	BELT DRIVE (E100)/(N-6M)	174,92 €(150,52 £)
# 17	23200-LKF5-E00	FACE ASSY DRIVEN	188,25 €(161,99 £)
# 18	23220-LKF5-E00	FACE COMP MOVABLE DRIVEN	137,42 €(118,25 £)
# 19	23225-LKF5-E00	PIN ROLLER GUIDE	8,75 €(7,53 £)
# 20	23233-LKF5-E00	SPRING DRIVEN FACE	23,25 €(20,01 £)
# 21	23237-LKF5-E00	COLLAR SPRING	14,08 €(12,12 £)
# 22	23238-LKF5-E01	COLLAR SPRING	9,58 €(8,24 £)
# 23	90201-LKF5-E00	NUT HEX	9,58 €(8,24 £)
# 24	90202-LDB5-E00	NUT SPECIAL (M36)	4,75 €(4,09 £)
# 25	90605-1F66-C00	CIRCLIP (7MM)	0,83 €(0,71 £)
# 26	91002-LKF5-E00	BEARING BALL	23,25 €(20,01 £)
# 27	91004-LBA2-E00	BEARING NEEDLE (25X33X18)	28,25 €(24,31 £)
# 28	91211-LDB5-E00	SEAL DRIVEN FACE (40, 2X47X4)	5,75 €(4,95 £)
# 29	91351-LDB5-E00	O-RING (48X46X2, 0)	2,42 €(2,08 £)
# 30	94050-LKF5-E00	NUT (M18)	9,58 €(8,24 £)
# 31	94520-30000	CIRCLIP IN (22MM)	0,58 €(0,50 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CLUTCH / VARIATOR of your Kymco XCITING 400I 4T EURO III of XCITING. Let us know if you have any questions.
