FRONT FORK

HANDLEBAR / SWITCHES FOR KYMCO XCITING 400I 4T EURO III

WARNING LABELS

(1) 17910-LKF5-E00

CABLE A COMP THROT

(2) 17911-LKF5-E00

CABLE B COMP THROT

(3) 3515A-LBA2-B70

SWITCH ASSY RIGHT HANDLE COMP (AHO)

(3) 3515A-LBA2-E01

SWITCH ASSY RIGHT HANDLE COMP

(4) 3520A-KEBE-900

SWITCH ASSY LEFT HANDLE COMP

(5) 53100-LKF5-E00

HANDLE COMP STRG

(6) 53102-LEA5-E00-NES

END LEFT HANDLE (MAT BLACK)

(7) 53105-LEA5-E00-NES

END RIGHT HANDLE (MAT BLACK)

(8) 53131-3H98-941

HOLDER UPPER HANDLE PIPE

(9) 53140-KKC4-900-N1R

GRIP COMP THROTTLE (BLACK BRUT)

(10) 53166-LEJ2-E10

GRIP LEFT HANDLE

(11) 53203-LBA2-E00-N1R

COVER METER FRONT (BLACK BRUT)

(12) 53204-LBA2-E00-N1R

COVER METER (BLACK BRUT)

(13) 53205-LKF5-E00-N1R

COVER HANDLE UP (BLACK BRUT)

(14) 53206-LKF5-E00-HUP

COVER REAR HANDLE (SILVER CRYSTAL)

(15) 53208-LKF5-E00-N1R

LID HANDLE UP (BLACK BRUT)

(16) 6413A-LGR2-E00-N1R

HOLDER ASSY RIGHT WIND SCREEN (BLACK BRUT)

(17) 64140-LKF5-E00-N1R

COVER RIGHT WIND SCREEN (BLACK BRUT)

(18) 64222-KKC4-900

RUBBER WIND SCREEN (9,5MM)

(19) 64222-LLJ3-E00

RUBBER WIND SCREEN (11MM)

(20) 6422A-LKF5-E00-T02

WIND SCREEN

(21) 64231-LBA2-E00

SPONGE TAPE RIGHT HOLDER

(22) 64232-LBA2-E00

SPONGE TAPE LEFT HOLDER

(23) 6423A-LGR2-E00-N1R

HOLDER ASSY LEFT WIND SCREEN (BLACK BRUT)

(24) 64240-LKF5-E00-N1R

COVER LEFT WIND SCREEN (BLACK BRUT)

(25) 87206-LBA2-E00-T01

EMBLEME KYMCO

(26) 87508-KKC4-E00-T01

LABEL CLEANNESS CAUYION

(27) 88110-LKF5-E00-N1P

MIRROR ASSY RIGHT BACK (SHINY BLACK)

(29) 88120-LKF5-E00-N1P

MIRROR ASSY LEFT BACK (SHINY BLACK)

(31) 90104-LEA7-E00

BOLT (M08X60)(BLACK)

(32) 90105-LLJ3-E00

BOLT (M08X16)(BLACK)

(33) 90111-KED9-900

VIS A TETE PLATE A SIX PANS CREUX DE 14 (M06X14 ARGENT)

(34) 90301-6D34-671

NUT (M06)

(35) 90302-SDA4-004

NUT SPRING (M04)

(36) 90312-GLF0-001

COLLAR (9,5MM)

(37) 90312-LLJ3-E00

COLLAR (11MM)

(38) 90656-KCBC-900

BAND HARNESS WIRE

(39) 90677-GAR1-C00

ECROU PRISONNIER M5

(40) 93404-06020-06

BOLT HEX (M06X20)(BLACK)

(41) 93500-05016-0H

SCREW PAN (M05X16)

(42) 93500-LBC6-900

SCREW PAN (M05X25)(GOLD)

(43) 93500-05032-1B

VIS A TETE PLATE CRUCIFORME DE 09 (M05X32 ARGENT)

(44) 93500-05045-1B

SCREW PAN (M05X45)(SILVER)

(45) 93903-35320

VIS TARAUDEUSE M05X16 (OR)

(46) 93903-GFY6-C00

VIS A TETE PLATE CRUCIFORME TARAUDEUSE DE 09 (M04X14 NOIR)

(47) 90131-LEB1-900

BOLT FLANGE (M08X35)(BLACK)

	Part number	Description	Qty
# 1	17910-LKF5-E00	CABLE A COMP THROT	19,08 €(16,34 £)
# 2	17911-LKF5-E00	CABLE B COMP THROT	19,08 €(16,34 £)
# 3	3515A-LBA2-B70	SWITCH ASSY RIGHT HANDLE COMP (AHO)	41,58 €(35,60 £)
# 3	3515A-LBA2-E01	SWITCH ASSY RIGHT HANDLE COMP	41,58 €(35,60 £)
# 4	3520A-KEBE-900	SWITCH ASSY LEFT HANDLE COMP	48,25 €(41,32 £)
# 5	53100-LKF5-E00	HANDLE COMP STRG	45,75 €(39,17 £)
# 6	53102-LEA5-E00-NES	END LEFT HANDLE (MAT BLACK)	11,25 €(9,63 £)
# 7	53105-LEA5-E00-NES	END RIGHT HANDLE (MAT BLACK)	11,25 €(9,63 £)
# 8	53131-3H98-941	HOLDER UPPER HANDLE PIPE	4,75 €(4,07 £)
# 9	53140-KKC4-900-N1R	GRIP COMP THROTTLE (BLACK BRUT)	11,25 €(9,63 £)
# 10	53166-LEJ2-E10	GRIP LEFT HANDLE	4,75 €(4,07 £)
# 11	53203-LBA2-E00-N1R	COVER METER FRONT (BLACK BRUT)	13,25 €(11,35 £)
# 12	53204-LBA2-E00-N1R	COVER METER (BLACK BRUT)	14,08 €(12,06 £)
# 13	53205-LKF5-E00-N1R	COVER HANDLE UP (BLACK BRUT)	19,08 €(16,34 £)
# 14	53206-LKF5-E00-HUP	COVER REAR HANDLE (SILVER CRYSTAL)	24,08 €(20,62 £)
# 15	53208-LKF5-E00-N1R	LID HANDLE UP (BLACK BRUT)	4,75 €(4,07 £)
# 16	6413A-LGR2-E00-N1R	HOLDER ASSY RIGHT WIND SCREEN (BLACK BRUT)	23,25 €(19,91 £)
# 17	64140-LKF5-E00-N1R	COVER RIGHT WIND SCREEN (BLACK BRUT)	2,67 €(2,29 £)
# 18	64222-KKC4-900	RUBBER WIND SCREEN (9, 5MM)	1,83 €(1,57 £)
# 19	64222-LLJ3-E00	RUBBER WIND SCREEN (11MM)	1,42 €(1,22 £)
# 20	6422A-LKF5-E00-T02	WIND SCREEN	141,58 €(121,23 £)
# 21	64231-LBA2-E00	SPONGE TAPE RIGHT HOLDER	7,92 €(6,78 £)
# 22	64232-LBA2-E00	SPONGE TAPE LEFT HOLDER	7,92 €(6,78 £)
# 23	6423A-LGR2-E00-N1R	HOLDER ASSY LEFT WIND SCREEN (BLACK BRUT)	23,25 €(19,91 £)
# 24	64240-LKF5-E00-N1R	COVER LEFT WIND SCREEN (BLACK BRUT)	2,67 €(2,29 £)
# 25	87206-LBA2-E00-T01	EMBLEME KYMCO	2,42 €(2,07 £)
# 26	87508-KKC4-E00-T01	LABEL CLEANNESS CAUYION	1,25 €(1,07 £)
# 27	88110-LKF5-E00-N1P	MIRROR ASSY RIGHT BACK (SHINY BLACK)	66,58 €(57,01 £)
# 29	88120-LKF5-E00-N1P	MIRROR ASSY LEFT BACK (SHINY BLACK)	66,58 €(57,01 £)
# 31	90104-LEA7-E00	BOLT (M08X60)(BLACK)	4,17 €(3,57 £)
# 32	90105-LLJ3-E00	BOLT (M08X16)(BLACK)	3,25 €(2,78 £)
# 33	90111-KED9-900	VIS A TETE PLATE A SIX PANS CREUX DE 14 (M06X14 ARGENT)	Not available	0,00 €(0,00 £)
# 34	90301-6D34-671	NUT (M06)	1,42 €(1,22 £)
# 35	90302-SDA4-004	NUT SPRING (M04)	1,17 €(1,00 £)
# 36	90312-GLF0-001	COLLAR (9, 5MM)	Not available	0,00 €(0,00 £)
# 37	90312-LLJ3-E00	COLLAR (11MM)	1,42 €(1,22 £)
# 38	90656-KCBC-900	BAND HARNESS WIRE	1,50 €(1,28 £)
# 39	90677-GAR1-C00	ECROU PRISONNIER M5	Not available	0,00 €(0,00 £)
# 40	93404-06020-06	BOLT HEX (M06X20)(BLACK)	1,33 €(1,14 £)
# 41	93500-05016-0H	SCREW PAN (M05X16)	Not available	0,00 €(0,00 £)
# 42	93500-LBC6-900	SCREW PAN (M05X25)(GOLD)	0,83 €(0,71 £)
# 43	93500-05032-1B	VIS A TETE PLATE CRUCIFORME DE 09 (M05X32 ARGENT)	Not available	0,00 €(0,00 £)
# 44	93500-05045-1B	SCREW PAN (M05X45)(SILVER)	0,83 €(0,71 £)
# 45	93903-35320	VIS TARAUDEUSE M05X16 (OR)	Not available	0,00 €(0,00 £)
# 46	93903-GFY6-C00	VIS A TETE PLATE CRUCIFORME TARAUDEUSE DE 09 (M04X14 NOIR)	Not available	0,00 €(0,00 £)
# 47	90131-LEB1-900	BOLT FLANGE (M08X35)(BLACK)	2,75 €(2,35 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the HANDLEBAR / SWITCHES of your Kymco XCITING 400I 4T EURO III of XCITING. Let us know if you have any questions.
