CYLINDER HEAD FOR KYMCO CV3 550 4T EURO 5

CYLINDER / PISTON

1231A

(1231A) 1231A-LGC6-E00

COVER COMP HEAD CYLINDER

1711A

(1711A) 1711A-AKB8-E00

PIPE ASSY INLET

1931A

(1931A) 1931A-LGC6-E00

COVER THERMOSTAT

3051A

(3051A) 3051A-LGC6-E00

COIL ASSY IGNITION

11384

(11384) 11384-LEA7-E05

CLAMPER TUBE

11384A

(11384A) 11384-LGC6-E02

CLAMPER TUBE

12200

(12200) 12200-LGC6-305

HEAD COMP CYLINDER

12208

(12208) 12208-LGC6-E00

SEAL TUBE SPARK

12209

(12209) 12209-LEA3-900

SEAL VALVE STEM

12251

(12251) 12251-LGC6-E00

GASKET CYLINDER HEAD

12391

(12391) 12391-LGC6-E00

GASKET HEAD COVER

14100

(14100) 14100-LGC6-E00

SHAFT COMP CAM IN

14200

(14200) 14200-LGC6-E00

SHAFT COMP CAM EX

14546

(14546) 14546-LGC6-E00

GUIDE UPPER TENSIONER

14711

(14711) 14711-LGC6-E00

VALVE INLET

14721

(14721) 14721-LGC6-E00

VALVE EXHAUST

14731

(14731) 14731-LGC6-E00

LIFTER VALVE

14751

(14751) 14751-LGC6-E00

SPRING VALVE OUTER

14771

(14771) 14771-LGC6-C00

SEAT VALVE SPRING

14773

(14773) 14773-LGC6-E00-01

SHIM 1,50

(14773) 14773-LGC6-E00-02

SHIM 1,55

(14773) 14773-LGC6-E00-03

SHIM 1,575

(14773) 14773-LGC6-E00-04

SHIM 1,60

(14773) 14773-LGC6-E00-05

SHIM 1,625

(14773) 14773-LGC6-E00-06

SHIM 1,65

(14773) 14773-LGC6-E00-07

SHIM 1,675

(14773) 14773-LGC6-E00-08

SHIM 1,70

(14773) 14773-LGC6-E00-09

SHIM 1,725

(14773) 14773-LGC6-E00-10

SHIM 1,75

(14773) 14773-LGC6-E00-11

SHIM 1,775

(14773) 14773-LGC6-E00-12

SHIM 1,80

(14773) 14773-LGC6-E00-13

SHIM 1,825

(14773) 14773-LGC6-E00-14

SHIM 1,85

(14773) 14773-LGC6-E00-15

SHIM 1,875

(14773) 14773-LGC6-E00-16

SHIM 1,90

(14773) 14773-LGC6-E00-17

SHIM 1,925

(14773) 14773-LGC6-E00-18

SHIM 1,95

(14773) 14773-LGC6-E00-19

SHIM 2,0

14777

(14777) 14777-LGC6-E00

SEAT VALVE SPRING

14781

(14781) 14781-LGC6-C00

COTTER VALVE

17810

(17810) 17810-LGC6-E00

RAIL COMP FUEL SUPPLY

19317

(19317) 19317-LBA2-E00

RING (48,3X2)

19319

(19319) 19319-LGC6-E00

BREATHABLE SCREW (M06X12)

19320

(19320) 19320-KED9-90A

THERMOSTAT ASSY

32101

(32101) 32101-AGJ5-E00

SUB HARNESS COIL

39300

(39300) 39300-KKE5-800

FUEL INJECTOR

39400

(39400) 39400-LEA6-800

SENSOR HEAD TEMPERATURE

90007

(90007) 90007-LGC6-E00

BOLT FLANGE (M09X160)

90018

(90018) 90018-KKE5-E00

BOLT ASSY HEAD COVER

90027

(90027) 90027-PUA5-E00

JACK SCREW M6 VALVE COVER (M06X17)

90033

(90033) 90033-KGB4-C00

BOLT STUD (M08X40)

(90478) 90478-7L00-001

WASHER (6MM)

90541

(90541) 90541-PUA5-E00

PROFILE SEALING WASHER

90652

(90652) 90652-GFY6-901

CLAMP (49,0MM)

91302

(91302) 91302-KKE5-800

SEAL RING

91302A

(91302A) 91302-LDB2-E00

O-RING (43X37X3)

94111

(94111) 94111-06800

WASHER SPRING (1,70X6,52X11,64)

94301

(94301) 94301-08140

PIN DOWEL (8X14)

94301A

(94301A) 94301-12200

PIN DOWEL (12X20X11)

96001

(96001) 96001-06018-06

BOLT FLANGE (M06X18)(BLACK)

96001A

(96001A) 96001-06130-06

BOLT FLANGE (M06X130)(BLACK)

96005

(96005) 96005-PRA1-E00

BOLT (M06X12)

96008

(96008) 96008-PRA1-E00

BOLT (M06X25)

96014

(96014) 96014-PRA1-E00

BOLT (M06X40)

96023

(96023) 96023-PRA1-E00

BOLT (M06X20)

98059

(98059) 98059-57916-00-0

SPARK PLUG NGK CR7E

	Part number	Description	Qty
# 1231A	1231A-LGC6-E00	COVER COMP HEAD CYLINDER	47,42 €(40,80 £)
# 1711A	1711A-AKB8-E00	PIPE ASSY INLET	24,08 €(20,72 £)
# 1931A	1931A-LGC6-E00	COVER THERMOSTAT	13,25 €(11,40 £)
# 3051A	3051A-LGC6-E00	COIL ASSY IGNITION	78,25 €(67,33 £)
# 11384	11384-LEA7-E05	CLAMPER TUBE	3,08 €(2,65 £)
# 11384A	11384-LGC6-E02	CLAMPER TUBE	2,67 €(2,30 £)
# 12200	12200-LGC6-305	HEAD COMP CYLINDER	500,00 €(430,25 £)
# 12208	12208-LGC6-E00	SEAL TUBE SPARK	1,25 €(1,08 £)
# 12209	12209-LEA3-900	SEAL VALVE STEM	2,92 €(2,51 £)
# 12251	12251-LGC6-E00	GASKET CYLINDER HEAD	38,25 €(32,91 £)
# 12391	12391-LGC6-E00	GASKET HEAD COVER	12,42 €(10,69 £)
# 14100	14100-LGC6-E00	SHAFT COMP CAM IN	141,58 €(121,83 £)
# 14200	14200-LGC6-E00	SHAFT COMP CAM EX	141,58 €(121,83 £)
# 14546	14546-LGC6-E00	GUIDE UPPER TENSIONER	9,58 €(8,24 £)
# 14711	14711-LGC6-E00	VALVE INLET	19,08 €(16,42 £)
# 14721	14721-LGC6-E00	VALVE EXHAUST	24,08 €(20,72 £)
# 14731	14731-LGC6-E00	LIFTER VALVE	16,58 €(14,27 £)
# 14751	14751-LGC6-E00	SPRING VALVE OUTER	7,42 €(6,38 £)
# 14771	14771-LGC6-C00	SEAT VALVE SPRING	1,50 €(1,29 £)
# 14773	14773-LGC6-E00-01	SHIM 1, 50	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-02	SHIM 1, 55	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-03	SHIM 1, 575	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-04	SHIM 1, 60	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-05	SHIM 1, 625	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-06	SHIM 1, 65	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-07	SHIM 1, 675	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-08	SHIM 1, 70	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-09	SHIM 1, 725	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-10	SHIM 1, 75	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-11	SHIM 1, 775	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-12	SHIM 1, 80	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-13	SHIM 1, 825	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-14	SHIM 1, 85	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-15	SHIM 1, 875	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-16	SHIM 1, 90	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-17	SHIM 1, 925	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-18	SHIM 1, 95	2,92 €(2,51 £)
# 14773	14773-LGC6-E00-19	SHIM 2, 0	2,92 €(2,51 £)
# 14777	14777-LGC6-E00	SEAT VALVE SPRING	2,50 €(2,15 £)
# 14781	14781-LGC6-C00	COTTER VALVE	1,92 €(1,65 £)
# 17810	17810-LGC6-E00	RAIL COMP FUEL SUPPLY	17,42 €(14,99 £)
# 19317	19317-LBA2-E00	RING (48, 3X2)	1,83 €(1,57 £)
# 19319	19319-LGC6-E00	BREATHABLE SCREW (M06X12)	1,08 €(0,93 £)
# 19320	19320-KED9-90A	THERMOSTAT ASSY	28,25 €(24,31 £)
# 32101	32101-AGJ5-E00	SUB HARNESS COIL	16,58 €(14,27 £)
# 39300	39300-KKE5-800	FUEL INJECTOR	124,92 €(107,49 £)
# 39400	39400-LEA6-800	SENSOR HEAD TEMPERATURE	20,75 €(17,86 £)
# 90007	90007-LGC6-E00	BOLT FLANGE (M09X160)	9,58 €(8,24 £)
# 90018	90018-KKE5-E00	BOLT ASSY HEAD COVER	4,75 €(4,09 £)
# 90027	90027-PUA5-E00	JACK SCREW M6 VALVE COVER (M06X17)	5,75 €(4,95 £)
# 90033	90033-KGB4-C00	BOLT STUD (M08X40)	1,92 €(1,65 £)
# 90478	90478-7L00-001	WASHER (6MM)	0,58 €(0,50 £)
# 90541	90541-PUA5-E00	PROFILE SEALING WASHER	5,75 €(4,95 £)
# 90652	90652-GFY6-901	CLAMP (49, 0MM)	3,08 €(2,65 £)
# 91302	91302-KKE5-800	SEAL RING	8,75 €(7,53 £)
# 91302A	91302-LDB2-E00	O-RING (43X37X3)	0,92 €(0,79 £)
# 94111	94111-06800	WASHER SPRING (1, 70X6, 52X11, 64)	0,67 €(0,58 £)
# 94301	94301-08140	PIN DOWEL (8X14)	1,42 €(1,22 £)
# 94301A	94301-12200	PIN DOWEL (12X20X11)	1,83 €(1,57 £)
# 96001	96001-06018-06	BOLT FLANGE (M06X18)(BLACK)	1,92 €(1,65 £)
# 96001A	96001-06130-06	BOLT FLANGE (M06X130)(BLACK)	1,42 €(1,22 £)
# 96005	96005-PRA1-E00	BOLT (M06X12)	0,67 €(0,58 £)
# 96008	96008-PRA1-E00	BOLT (M06X25)	1,33 €(1,14 £)
# 96014	96014-PRA1-E00	BOLT (M06X40)	1,17 €(1,01 £)
# 96023	96023-PRA1-E00	BOLT (M06X20)	2,08 €(1,79 £)
# 98059	98059-57916-00-0	SPARK PLUG NGK CR7E	11,58 €(9,96 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER HEAD of your Kymco CV3 550 4T EURO 5 of CV3. Let us know if you have any questions.
