STEERING FOR KYMCO CV3 550 4T EURO 5

EXHAUST

38705

(38705) 38705-AGJ5-E00

ANTENNA COMP SHORT RANGE

38707

(38707) 38707-AGJ5-E00

ADAPTER STAY SHORT RANGE ANTENNA

38708

(38708) 38708-AGJ5-E00

STAY ANTENNA SHORT RANGE

48100

(48100) 48100-AGJ5-E00

CONTROLLEUR HYDRAULIQUE

48205

(48205) 48205-AGJ5-E00

SUPPORT DE CONTROLLEUR HYDRAULIQUE

53400

(53400) 53400-AGJ5-E00

TILTING ARM ASSY UPR RH/LH

53502

(53502) 53502-AGJ5-E00

COLLAR A, UPR TILTING ARM

53503

(53503) 53503-AGJ5-E00

SIDE COLLAR,UPR TILTING ARM

53504

(53504) 53504-AGJ5-E00

COLLAR B,UPR TILTING ARM

53550

(53550) 53550-AGJ5-E00

TILTING ARM ASSY,LWR FR

53553

(53553) 53553-AGJ5-E00

SIDE COLLAR,LWR TILTING ARM

53554

(53554) 53554-AGJ5-E00

CAP,TILTING ARM

53555

(53555) 53555-AGJ5-E00

SOCKET BOLT,UPR TILTING ARM

53560

(53560) 53560-AGJ5-E00

TILTING ARM ASSY,LWR REAR

53562

(53562) 53562-AGJ5-E00

LOCK PIN,LWR TILTING ARM

53900

(53900) 53900-AGJ5-E00

ELEC. ANTI-TILTING BRAKE ASSY

53921

(53921) 53921-AGJ5-E00

DISK,ANTI-TILTING BRAKE

90105

(90105) 90105-KCR3-010

BOLT (M08X24)

90304

(90304) 90304-GLW0-90A

NUT FLANGE (M10X10)

90306

(90306) 90306-GLW0-90A

NUT FLANGE (M12X13)

93893

(93893) 93893-04012-0G

SCREW WASHER (M04X12)

94050

(94050) 94050-10080-G

NUT (M10)

94520

(94520) 94520-40000

CIRCLIP IN (40MM)

94520A

(94520A) 94520-42000

CIRCLIP IN (42MM)

94520B

(94520B) 94520-47000

CIRCLIP IN (47MM)

95701-08025

(95701-08025) 95701-08025-08G

BOLT FLANGE (M08X25)(GOLD)

95801-08030

(95801-08030) 95801-08030-08G

BOLT FLANGE (M08X30)

95801-10075

(95801-10075) 95801-10075-06

BOLT FLANGE (M10X75)(BLACK)

95801-10120

(95801-10120) 95801-10120-06

BOLT FLANGE (M10X120)(BLACK)

95801-AGJ5

(95801-AGJ5) 95801-AGJ5-E00

BOLT FLANGE (M12X35)

96001

(96001) 96001-06010-08G

BOLT FLANGE (M06X10)

96150

(96150) 96150-63020-10

BEARING BALL (6302)(15X43X13)

96150A

(96150A) 96150-63030-10

BEARING BALL (6303 LU)(17X47X14)

	Part number	Description	Qty
# 38705	38705-AGJ5-E00	ANTENNA COMP SHORT RANGE	14,08 €(12,06 £)
# 38707	38707-AGJ5-E00	ADAPTER STAY SHORT RANGE ANTENNA	2,17 €(1,86 £)
# 38708	38708-AGJ5-E00	STAY ANTENNA SHORT RANGE	4,75 €(4,07 £)
# 48100	48100-AGJ5-E00	CONTROLLEUR HYDRAULIQUE	Not available	0,00 €(0,00 £)
# 48205	48205-AGJ5-E00	SUPPORT DE CONTROLLEUR HYDRAULIQUE	Not available	0,00 €(0,00 £)
# 53400	53400-AGJ5-E00	TILTING ARM ASSY UPR RH/LH	474,92 €(406,89 £)
# 53502	53502-AGJ5-E00	COLLAR A, UPR TILTING ARM	3,92 €(3,36 £)
# 53503	53503-AGJ5-E00	SIDE COLLAR, UPR TILTING ARM	3,58 €(3,07 £)
# 53504	53504-AGJ5-E00	COLLAR B, UPR TILTING ARM	6,00 €(5,14 £)
# 53550	53550-AGJ5-E00	TILTING ARM ASSY, LWR FR	189,92 €(162,71 £)
# 53553	53553-AGJ5-E00	SIDE COLLAR, LWR TILTING ARM	4,75 €(4,07 £)
# 53554	53554-AGJ5-E00	CAP, TILTING ARM	2,75 €(2,36 £)
# 53555	53555-AGJ5-E00	SOCKET BOLT, UPR TILTING ARM	4,75 €(4,07 £)
# 53560	53560-AGJ5-E00	TILTING ARM ASSY, LWR REAR	195,75 €(167,71 £)
# 53562	53562-AGJ5-E00	LOCK PIN, LWR TILTING ARM	2,75 €(2,36 £)
# 53900	53900-AGJ5-E00	ELEC. ANTI-TILTING BRAKE ASSY	395,75 €(339,06 £)
# 53921	53921-AGJ5-E00	DISK, ANTI-TILTING BRAKE	56,58 €(48,47 £)
# 90105	90105-KCR3-010	BOLT (M08X24)	2,25 €(1,93 £)
# 90304	90304-GLW0-90A	NUT FLANGE (M10X10)	1,50 €(1,29 £)
# 90306	90306-GLW0-90A	NUT FLANGE (M12X13)	2,42 €(2,07 £)
# 93893	93893-04012-0G	SCREW WASHER (M04X12)	0,92 €(0,79 £)
# 94050	94050-10080-G	NUT (M10)	1,42 €(1,22 £)
# 94520	94520-40000	CIRCLIP IN (40MM)	1,25 €(1,07 £)
# 94520A	94520-42000	CIRCLIP IN (42MM)	1,25 €(1,07 £)
# 94520B	94520-47000	CIRCLIP IN (47MM)	5,42 €(4,64 £)
# 95701-08025	95701-08025-08G	BOLT FLANGE (M08X25)(GOLD)	1,50 €(1,29 £)
# 95801-08030	95801-08030-08G	BOLT FLANGE (M08X30)	2,92 €(2,50 £)
# 95801-10075	95801-10075-06	BOLT FLANGE (M10X75)(BLACK)	2,42 €(2,07 £)
# 95801-10120	95801-10120-06	BOLT FLANGE (M10X120)(BLACK)	2,50 €(2,14 £)
# 95801-AGJ5	95801-AGJ5-E00	BOLT FLANGE (M12X35)	4,75 €(4,07 £)
# 96001	96001-06010-08G	BOLT FLANGE (M06X10)	1,17 €(1,00 £)
# 96150	96150-63020-10	BEARING BALL (6302)(15X43X13)	7,92 €(6,79 £)
# 96150A	96150-63030-10	BEARING BALL (6303 LU)(17X47X14)	12,08 €(10,35 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STEERING of your Kymco CV3 550 4T EURO 5 of CV3. Let us know if you have any questions.
