5. FUEL SYSTEM AGILITY 125
CARBURETOR REMOVAL
Remove the frame right side cover. ( 2-4)
Disconnect the auto bystarter wire
connector.
Remove the met-in box. ( 2-3)
Auto Bystarter Wire Auto Bystarter
Loosen the drain screw and drain the fuel
from the float chamber.
Disconnect the fuel tube and vacuum tube at
the carburetor.
Fuel Tube
Air Cleaner Connecting Vacuum Tube Intake Manifold
Tube Band Band
Loosen the throttle cable adjusting nut and
lock nut, and disconnect the throttle cable
from the carburetor.
Loosen the carburetor intake manifold band
and air cleaner connecting tube band screws
and then remove the carburetor.
Throttle Cable Adjusting Nut Lock Nut
AUTO BYSTARTER
OPERATION INSPECTION
Measure the resistance between the auto
bystarter wire terminals.
Resistance: 10 max. (10 minutes
minimum after stopping the engine)
If the reading is not within the limit, replace
the auto bystarter with a new one.
5-4
