5. FUEL SYSTEM AGILITY 125
FUEL UNIT Fuel Unit Wire
REMOVAL
Remove the related parts.
Disconnect the fuel unit wire connector.
Turn the fixed plate on the fuel unit,take the
fuel unit off.
Do not bend the float arm on the fuel
unit,otherwise the figure on the fuel
meter will not correct.
INSTALLATION Fuel Tank
Inspet if the fuel unit is damaged,or harden.
Assemble the fuel unit in the reverse order
of disassembly.
· Align the groove on the fuel unit with
the angle on the fuel tank.
· Inspect if the fuel tank leaked after
installing and filling the gasoling.
Fuel Unit Align Mark
AIR CLEANER air cleaner
Loosen the air cleaner connecting tube band
screw.
Disconnect the clinhead cover breather tube
from the air cleaner.
Remove the two bolts and air cleaner case.
bolts
5-13
