12. COOLING SYSTEM GRAND DINK 250
WATER PUMP SHAFT REMOVAL Bolts
Disconnect the water hose from the right
crankcase cover.
Remove the eight bolts attaching the right
crankcase cover.
Water Pump Assembly
Water Pump Assembly Inner Bearing
Remove the water pump bearing snap ring
from the water pump assembly.
Remove the water pump shaft and inner
bearing.
Snap Ring Water Pump Shaft
Water Pump Assembly
Remove the water pump shaft outer
bearing.
Inner Bearing
12-11
