                                                                       9. Install the input driveshaft.




                                                    KC325
7. Align the inner shift fork with the gear cluster and
   with the inner washer in place, install the gear                                                           MD1326

   cluster and inner shift fork. While holding the gear     10. Install the washer, spacer, sleeve, and reverse idler
   cluster in place, install the washer, gear, and snap         gear.
   ring.



                                                                                                                        3



                                                                                                              MD1357
                                                   MD1032   11. Install the secondary and primary driveshaft
                                                                assemblies. Account for the bearing alignment
                                                                C-ring on the bearing boss next to the pinion gear.
                                                             NOTE: Align the bearing alignment pin on the
                                                            secondary output shaft.




                                                   MD1198
8. Install the outer shift fork and the shift fork shaft.



                                                                                                              MD1316




                                                   MD1327

                                                                                                                3-43
