Measuring Connecting Rod 2. Acceptable width range must be within specifica- (Big End Width) tions. 1. Using a calipers, measure the width of the COUNTERSHAFT connecting rod at the big-end bearing. ! CAUTION 2. Acceptable width range must be within specifica- tions. When disassembling the countershaft, care must be taken to note the direction each major component Measuring Crankshaft (Runout) (dog, gear) faces. If a major component is installed facing the wrong direction, transmission damage 1. Place the crankshaft on a set of V blocks. may occur and/or the transmission will malfunction. In either case, complete disassembly and assembly 2. Mount a dial indicator and base on the surface will be required. plate. Position the indicator contact at point 1 of the crankshaft. Disassembling 1. Remove the reverse driven gear dog; then remove the circlip securing the reverse driven gear. 2. Remove the reverse driven gear and account for the washer, bushing, and bearing. 3. Remove the low driven gear washer; then remove the low driven gear. Account for the bushing and 3 bearing. 4. Remove the washer; then remove the circlip secur- ing the sliding dog. Remove the sliding dog. ATV-1074 5. Remove the high driven gear circlip; then remove the high driven gear. Account for the washer, 3. Zero the indicator and rotate the crankshaft slowly. bushing, and bearing. ! CAUTION Assembling Care should be taken to support the connecting rod 1. Place the high driven gear onto the countershaft when rotating the crankshaft. making sure the bearing, bushing, and washer are 4. Maximum runout must not exceed specifications. properly positioned. Secure with the circlip. NOTE: Proceed to check runout on the other end 2. Place the sliding dog onto the countershaft; then secure with the circlip. Place the washer next to of the crankshaft by positioning the indicator con- the circlip. tact at point 2 and following steps 3-4. 3. Place the low driven gear onto the countershaft Measuring Crankshaft making sure the bearing and bushing are properly (Web-to-Web) positioned; then place the washer onto the shaft. 1. Using a calipers, measure the distance from the 4. Place the reverse driven gear onto the countershaft outside edge of one web to the outside edge of the making sure the bearing, bushing, and washer are other web. properly positioned; then secure with the circlip. 5. Place the reverse driven gear dog onto the counter- shaft. NOTE: The countershaft is now completely assembled for installation. ATV-1017 3-41
